2012 Motorhispania RYZ 49 Pro Racing Supermotard. Picture credits - Motorhispania.
Submit more pictures.
|
|
| Motorhispania's profilation of this bike |
| The Ryz elevated to the maximum power. |
| General moped information |
|---|
| Model | Motorhispania RYZ 49 Pro Racing Supermotard |
| Year | 2012 |
| Category | Enduro / offroad |
| Rating | Do you know this bike?
Click here to rate it. We miss 1 vote to show the rating. |
| Engine and transmission |
|---|
| Displacement | 49.7 ccm (3.03 cubic inches) |
| Engine type | Single cylinder, four-stroke |
| Engine details | Minarelli AM 6 |
| Compression | 12.0:1 |
| Bore x stroke | 40.3 x 39.0 mm (1.6 x 1.5 inches) |
| Fuel system | Carburettor. PHBN 16 |
| Fuel control | Single Overhead Cams (SOHC) |
| Ignition | C.D.I. |
| Cooling system | Liquid |
| Gearbox | 6-speed |
| Clutch | Multiidsk in oil coating |
| Chassis, suspension, brakes and wheels |
|---|
| Frame type | Double steel beam |
| Front suspension | Inverted hydraulic fork 38 mm advance axle |
| Rear suspension | Olle mono shock absorber, seprate bottle |
| Front tire | 100/80-17 |
| Rear tire | 130/70-17 |
| Front brakes | Single disc |
| Diameter | 240 mm (9.4 inches) |
| Rear brakes | Single disc |
| Diameter | 200 mm (7.9 inches) |
| Physical measures and capacities |
|---|
| Dry weight | 94.0 kg (207.2 pounds) |
| Overall length | 1980 mm (78.0 inches) |
| Wheelbase | 1350 mm (53.1 inches) |
| Fuel capacity | 7.80 litres (2.06 US gallons) |
| Other specifications |
|---|
| Color options | Blue, black |
| Starter | Kick |
| Factory warranty | 2 years unlimited mileage |
| Comments | Motorhispania, also called MH Motorcycles, is from Spain. |
| Update specs | Report missing specs or required updates. |
| Further information |
|---|
| Insurance costs | Compare US insurance quotes from the nation's top providers. |
| Finance options | Compare US motorcycle loan quotes from the nation's top providers. |
| Parts finder | Revzilla offers up to 50% off motorcycle accessories. Ships to most countries.
Also check out our overview of motorcycle webshops at Bikez.info. |
| Dirt-bike parts | Dirt-bike parts and gear available from Mega Motor Madness . Ships to most countries. |
| Maintenance | Find parts, fluids. filters, maintenance tools and service manuals at Amazon.com. |
| Ask questions | Join the 12 Motorhispania RYZ 49 Pro Racing Supermotard discussion group or the general Motorhispania discussion group. |
| Related bikes | List related bikes for comparison of specs. |
|
|
