General information |
|
Motorcycle name
|
Moto Guzzi V11 Le Mans |
|
Year of manufacture
|
2003 |
|
Type
|
Sport |
|
Rating
|
3.3 Check out the detailed rating of racing track capabilities, engine performance, accident risk, etc. Compare with any other bike. |
|
Engine and transmission |
|
Engine size
|
1064.0 ccm (64.93 cubic inches) |
|
Type of engine
|
V2, four-stroke |
|
Output
|
90.0 HP (65.7 kW)) @ 7800 RPM |
|
Torque
|
94.1 Nm (9.6 kgf-m or 69.4 ft.lbs) @ 6000 RPM |
|
Top speed
|
214.0 km/h (133.0 mph) |
|
Compression
|
9.8:1 |
|
Bore x stroke
|
92.0 x 80.0 mm (3.6 x 3.1 inches) |
|
Fuel system
|
Injection |
|
Fuel control
|
Overhead Valves (OHV) |
|
Ignition
|
Magneti Marelli IAW electronic digital |
|
Cooling system
|
Air |
|
Gearbox
|
5-speed |
|
Transmission type
|
Chain (final drive) |
|
Chassis, suspension, brakes and wheels |
|
Trail
|
103 mm (4.1 inches) |
|
Front suspension
|
40mm Marzocchi upside-down forks, adjustable compression |
|
Front wheel travel
|
120 mm (4.7 inches) |
|
Rear suspension
|
Cantilever swingarm, Sachs Boge mono shock, adjustable compression and rebound damping |
|
Rear wheel travel
|
128 mm (5.0 inches) |
|
Front tire
|
120/70-17 |
|
Rear tire
|
170/60-17 |
|
Front brakes
|
Double disc. Four-piston calipers. |
|
Diameter
|
320 mm (12.6 inches) |
|
Rear brakes
|
Single disc. Two-piston calipers. |
|
Diameter
|
282 mm (11.1 inches) |
|
Physical measures and capacities |
|
Dry weight
|
226.0 kg (498.2 pounds) |
|
Power/weight ratio
|
0.3982 HP/kg |
|
Seat height
|
800 mm (31.5 inches) If adjustable, lowest setting. |
|
Overall length
|
2150 mm (84.6 inches) |
|
Ground clearance
|
178 mm (7.0 inches) |
|
Wheelbase
|
1490 mm (58.7 inches) |
|
Fuel capacity
|
22.00 litres (5.81 US gallons) |
|
Other specifications |
|
Color options
|
Red, Black |
|
Starter
|
Electric |
