| Husqvarna's profilation of this bike |
| The TE125 is the new four stroke 125 cc model from Husqvarna, aimed at young fans of the brand. It inherits a look that is particularly aggressive and appealing, reflecting the style of the bikes used in races by the official Husqvarna team. |
|
General information |
|
Model name
|
Husqvarna TE125 |
|
Year of manufacture
|
2012 |
|
Type
|
Enduro / offroad |
|
Rating
|
3.0 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
|
Engine and transmission |
|
Engine size
|
124.5 ccm (7.59 cubic inches) |
|
Type of engine
|
Single cylinder, four-stroke |
|
Bore x stroke
|
52.0 x 58.6 mm (2.0 x 2.3 inches) |
|
Valves per cylinder
|
4 |
|
Fuel system
|
Carburettor. Keihin 29 Carburettor |
|
Fuel control
|
Single Overhead Cams (SOHC) |
|
Lubrication system
|
Wet sump with lobe oil pump and cartridge filter |
|
Cooling system
|
Liquid |
|
Gearbox
|
6-speed |
|
Transmission type
|
Chain (final drive) |
|
Clutch
|
Multi plate, cable operation |
|
Driveline
|
6 speed constant mesh |
|
Chassis, suspension, brakes and wheels |
|
Front suspension
|
40mm Paioli Upside-Down telescopic hydraulic fork with advanced axle |
|
Front wheel travel
|
260 mm (10.2 inches) |
|
Rear suspension
|
Sachs Progressive ´Soft Damp´ type with single hydraulic shock absorber; spring preload adjustment. |
|
Rear wheel travel
|
290 mm (11.4 inches) |
|
Front tire
|
90/90-21 |
|
Rear tire
|
120/80-18 |
|
Front brakes
|
Single disc. Fixed disc with hydraulic control and floating caliper |
|
Diameter
|
260 mm (10.2 inches) |
|
Rear brakes
|
Single disc. Fixed disc with hydraulic control and floating caliper |
|
Diameter
|
220 mm (8.7 inches) |
|
Physical measures and capacities |
|
Weight incl. oil, gas, etc
|
117.0 kg (257.9 pounds) |
|
Seat height
|
930 mm (36.6 inches) If adjustable, lowest setting. |
|
Overall height
|
1230 mm (48.4 inches) |
|
Overall length
|
2235 mm (88.0 inches) |
|
Overall width
|
800 mm (31.5 inches) |
|
Ground clearance
|
305 mm (12.0 inches) |
|
Wheelbase
|
1450 mm (57.1 inches) |
|
Fuel capacity
|
9.50 litres (2.51 US gallons) |
|
Other specifications |
|
Color options
|
Red/white/black |
|
Starter
|
Electric |
|
Instruments
|
Digital dash |
|
Factory warranty
|
2 Years |
