| Husqvarna's profilation of this bike |
| The seat, fuel tank, side panels, air ducts and mudguards at the front and rear all have a new design. The seat has new dual density padding to ensure greater comfort for rider and passenger even on longer routes. The passenger also has two convenient grab handles anchored to the rear sub-frame for a safer, more comfortable ride. |
|
General information |
|
Model
|
Husqvarna SMR630 |
|
Year
|
2013 |
|
Category
|
Super motard |
|
Rating
|
Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
|
Engine and transmission |
|
Displacement
|
600.0 ccm (36.61 cubic inches) |
|
Engine type
|
Single cylinder, four-stroke |
|
Compression
|
12.4:1 |
|
Bore x stroke
|
100.0 x 76.4 mm (3.9 x 3.0 inches) |
|
Valves per cylinder
|
4 |
|
Fuel system
|
Injection. Mikuni Digital |
|
Fuel control
|
Double Overhead Cams/Twin Cam (DOHC) |
|
Ignition
|
Electronic, inductive discharge, with adjustable advance (digital control) |
|
Lubrication system
|
Wet sump with oil pump and cartridge filter |
|
Cooling system
|
Liquid |
|
Gearbox
|
6-speed |
|
Transmission type
|
Chain (final drive) |
|
Clutch
|
Wet, multi-plate type, hydraulic control |
|
Driveline
|
6 speed constant mesh |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Steel single tube cradle; rear frame in light alloy |
|
Trail
|
83 mm (3.3 inches) |
|
Front suspension
|
Marzocchi USD telescopic hydraulic fork with advanced axle, rebound stroke adjustment |
|
Front wheel travel
|
250 mm (9.8 inches) |
|
Rear suspension
|
Sachs Progressive Soft Damp type with single hydraulic shock absorber, spring pre-load adjustment. Compression and rebound adjustment (compression stroke - double adjustment) |
|
Rear wheel travel
|
290 mm (11.4 inches) |
|
Front tire
|
120/70-17 |
|
Rear tire
|
150/60-17 |
|
Front brakes
|
Single disc. Floating disc with hydraulic control and radial caliper |
|
Diameter
|
320 mm (12.6 inches) |
|
Rear brakes
|
Single disc. Floating disc with hydraulic control and floating caliper |
|
Diameter
|
220 mm (8.7 inches) |
|
Physical measures and capacities |
|
Dry weight
|
151.0 kg (332.9 pounds) |
|
Seat height
|
910 mm (35.8 inches) If adjustable, lowest setting. |
|
Overall height
|
1190 mm (46.9 inches) |
|
Overall length
|
2170 mm (85.4 inches) |
|
Overall width
|
840 mm (33.1 inches) |
|
Ground clearance
|
240 mm (9.4 inches) |
|
Wheelbase
|
1495 mm (58.9 inches) |
|
Fuel capacity
|
12.00 litres (3.17 US gallons) |
|
Other specifications |
|
Color options
|
White/black/red |
|
Starter
|
Electric |
|
Instruments
|
Digital dash |
|
Light
|
60W headlight |
|
Factory warranty
|
2 Years |
