| General information |
|---|
| Model: | Husqvarna CR125 |
| Year: | 2012 |
| Category: | Cross / motocross |
| Price as new: | US$ 5999. MSRP depends on country, taxes, accessories, etc. |
| Rating: | 3.2 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
| Engine and transmission |
|---|
| Displacement: | 144.0 ccm (8.79 cubic inches) |
| Engine type: | Single cylinder, two-stroke |
| Engine details: | Reed valve in crankcase with power valve |
| Compression: | 8.8:1 |
| Bore x stroke: | 58.0 x 58.0 mm (2.3 x 2.3 inches) |
| Fuel system: | Carburettor. Mikuni TMX38 |
| Gearbox: | 6-speed |
Transmission type,
final drive: | Chain |
| Clutch: | Wet multi-plate |
| Driveline: | Constant mesh |
| Chassis, suspension, brakes and wheels |
|---|
| Frame type: | Chromoly single tube frame cradle utilizes rounded-rectangle elliptical tubing. |
| Front suspension: | Marzocchi 48mm forks. Upside down (USD) forks with compression and rebound adjustment |
| Rear suspension: | Sachs single shock with remote reservoir, adjustable spring preload, compression and rebound damping. |
| Front tyre: | 90/90-21 |
| Rear tyre: | 2.15-18 |
| Front brakes: | Single disc |
| Diameter: | 260 mm (10.2 inches) |
| Rear brakes: | Single disc |
| Diameter: | 240 mm (9.4 inches) |
| Physical measures and capacities |
|---|
| Dry weight: | 92.0 kg (202.8 pounds) |
| Seat height: | 985 mm (38.8 inches) If adjustable, lowest setting. |
| Overall length: | 2215 mm (87.2 inches) |
| Overall width: | 820 mm (32.3 inches) |
| Ground clearance: | 325 mm (12.8 inches) |
| Wheelbase: | 1460 mm (57.5 inches) |
| Fuel capacity: | 7.00 litres (1.85 gallons) |
| Oil capacity: | 0.80 litres (0.85 US quarts) |
| Other specifications |
|---|
| Color options: | Red/White |
| Starter: | Kick |
| Factory warranty: | 2 Years |
| Comments: | The model comes with a 144cc top-end kit complete with cylinder and piston for adding 19cc. |
