| General information |
|---|
| Model | Benelli TNT 1130 Titanium |
| Year | 2011 |
| Category | Naked bike |
| Rating | 2.9 See the detailed rating of engine performance, design and look, accident risk, etc. Compare with any other motorcycle. |
| Engine and transmission |
|---|
| Displacement | 1131.0 ccm (69.01 cubic inches) |
| Engine type | In-line three, four-stroke |
| Engine details | Cylinders tilted forward 15 degrees. Anti-vibration countershafts |
| Power | 140.8 HP (102.8 kW)) @ 9250 RPM |
| Torque | 122.0 Nm (12.4 kgf-m or 90.0 ft.lbs) @ 6750 RPM |
| Bore x stroke | 88.0 x 62.0 mm (3.5 x 2.4 inches) |
| Valves per cylinder | 4 |
| Fuel system | Injection |
| Fuel control | Double Overhead Cams/Twin Cam (DOHC) |
| Lubrication system | Wet sump |
| Cooling system | Liquid |
| Gearbox | 6-speed |
| Transmission type | Chain (final drive) |
| Clutch | Dry clutch |
| Driveline | Straight toothed primary gear, chain final |
| Chassis, suspension, brakes and wheels |
|---|
| Frame type | Decomposable, front ASD steel trellis, rear alluminium alloy casting |
| Rake (fork angle) | 24.0° |
| Trail | 95 mm (3.7 inches) |
| Front suspension | Marzocchi upside down fork totally adjustable Ø 50 mm |
| Front wheel travel | 120 mm (4.7 inches) |
| Rear suspension | ASD steel tube trellis swingarm with totally adjustable shock absorber |
| Rear wheel travel | 120 mm (4.7 inches) |
| Front tire | 120/70-;17 |
| Rear tire | 180/55-;17 |
| Front brakes | Single disc. Bremo, floating disk |
| Diameter | 320 mm (12.6 inches) |
| Rear brakes | Single disc. Bremo |
| Diameter | 220 mm (8.7 inches) |
| Wheels | Marchesini forged aluminium |
| Physical measures and capacities |
|---|
| Dry weight | 193.0 kg (425.5 pounds) |
| Power/weight ratio | 0.7296 HP/kg |
| Seat height | 780 mm (30.7 inches) If adjustable, lowest setting. |
| Overall length | 2100 mm (82.7 inches) |
| Overall width | 790 mm (31.1 inches) |
| Wheelbase | 1419 mm (55.9 inches) |
| Fuel capacity | 17.00 litres (4.49 US gallons) |
| Reserve fuel capacity | 4.00 litres (1.06 US gallons) |
| Other specifications |
|---|
| Color options | Titanium/red/black |
| Starter | Electric |
