| BamX's profilation of this bike |
| Being fully automatic this ATV is ideal and especially attractive for those whose style is life on movement. This ATV is simple in use for any age category. This utility vehicle is an ideal machine for a long journey as well. |
|
General information |
|
Model
|
BamX BX700-U4 Tahoe |
|
Year model
|
2012 |
|
Type
|
ATV |
| Price as new | US$ 5999. MSRP depends on country, taxes, accessories, etc. |
|
Rating
|
Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
|
Engine and transmission |
|
Engine size
|
686.0 ccm (41.86 cubic inches) |
|
Type of engine
|
Single cylinder, four-stroke |
|
Effect
|
16.1 HP (11.7 kW)) @ 6000 RPM |
|
Torque
|
49.0 Nm (5.0 kgf-m or 36.1 ft.lbs) @ 5000 RPM |
|
Compression
|
9.2:1 |
|
Bore x stroke
|
102.0 x 84.0 mm (4.0 x 3.3 inches) |
|
Fuel system
|
Carburettor. PD42J |
|
Ignition
|
CDI |
|
Lubrication system
|
Pressure/Splash |
|
Cooling system
|
Liquid |
|
Chassis, suspension, brakes and wheels |
|
Front suspension
|
Independent double swing arm |
|
Rear suspension
|
Independent double swing arm |
|
Front tire
|
25/8-12 |
|
Rear tire
|
25/10-12 |
|
Front brakes
|
Double disc |
|
Rear brakes
|
Single disc |
|
Seat
|
One person seat |
|
Physical measures and capacities |
|
Dry weight
|
310.0 kg (683.4 pounds) |
|
Power/weight ratio
|
0.0519 HP/kg |
|
Seat height
|
870 mm (34.3 inches) If adjustable, lowest setting. |
|
Ground clearance
|
260 mm (10.2 inches) |
|
Wheelbase
|
1365 mm (53.7 inches) |
|
Fuel capacity
|
17.00 litres (4.49 US gallons) |
|
Other specifications |
|
Color options
|
Green camo, brown camo |
|
Starter
|
Electric & kick |
|
Light
|
12V35W/35W x 2, 12V5W x 2(front) |
