| General information |
|---|
| Model: | AJS Eco-125 |
| Year: | 2009 |
| Category: | Allround |
| Rating: | 3.4 Check out the detailed rating of reliability, maintenance costs, value for money, etc. Compare with any other motorcycle. |
| Engine and transmission |
|---|
| Displacement: | 124.0 ccm (7.57 cubic inches) |
| Engine type: | Single cylinder, four-stroke |
| Power: | 10.1 HP (7.3 kW)) @ 8000 RPM |
| Bore x stroke: | 54.0 x 54.0 mm (2.1 x 2.1 inches) |
| Fuel system: | Carburettor |
| Fuel control: | Overhead Cams (OHC) |
| Ignition: | Coil CDI |
| Cooling system: | Air |
| Gearbox: | 5-speed |
Transmission type,
final drive: | Chain |
| Clutch: | Wet, multiplate |
| Chassis, suspension, brakes and wheels |
|---|
| Front suspension: | Telefork |
| Rear suspension: | Adjustable load, oil damped twin shocks |
| Front tire: | 2.75-18 |
| Rear tire: | 90/90-18 |
| Front brakes: | Single disc |
| Rear brakes: | Expanding brake (drum brake) |
| Physical measures and capacities |
|---|
| Dry weight: | 114.0 kg (251.3 pounds) |
| Power/weight ratio: | 0.0882 HP/kg |
| Seat height: | 760 mm (29.9 inches) If adjustable, lowest setting. |
| Wheelbase: | 1080 mm (42.5 inches) |
| Other specifications |
|---|
| Color options: | Black, metallic blue, Rosso red |
| Starter: | Electric & kick |
| Comments: | Chinese bikes sold in the UK. |
