General information |
|
Motorcycle name
|
Yamaha YZF-R125 |
|
Year of manufacture
|
2013 |
|
Type
|
Sport |
|
Rating
|
3.5 Check out the detailed rating of racing track capabilities, engine performance, accident risk, etc. Compare with any other bike. |
|
Engine and transmission |
|
Engine size
|
124.7 ccm (7.61 cubic inches) |
|
Type of engine
|
Single cylinder, four-stroke |
|
Output
|
14.8 HP (10.8 kW)) |
|
Torque
|
12.2 Nm (1.2 kgf-m or 9.0 ft.lbs) |
|
Compression
|
11.2:1 |
|
Bore x stroke
|
52.0 x 58.6 mm (2.0 x 2.3 inches) |
|
Valves per cylinder
|
4 |
|
Fuel system
|
Injection. EFI |
|
Fuel control
|
Single Overhead Cams (SOHC) |
|
Ignition
|
TCI |
|
Lubrication system
|
Wet sump |
|
Cooling system
|
Liquid |
|
Gearbox
|
6-speed |
|
Transmission type
|
Chain (final drive) |
|
Clutch
|
Wet, multiple-disc coil spring |
|
Driveline
|
Constant Mesh |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Steel deltabox frame and aluminium swinging arm |
|
Rake (fork angle)
|
24.2° |
|
Trail
|
86 mm (3.4 inches) |
|
Front suspension
|
Telescopic forks |
|
Front wheel travel
|
130 mm (5.1 inches) |
|
Rear suspension
|
Linked monoshock with spring preload adjustment |
|
Rear wheel travel
|
125 mm (4.9 inches) |
|
Front tire
|
100/80-M17 |
|
Rear tire
|
130/70-M17 |
|
Front brakes
|
Single disc |
|
Diameter
|
292 mm (11.5 inches) |
|
Rear brakes
|
Single disc |
|
Diameter
|
230 mm (9.1 inches) |
|
Physical measures and capacities |
|
Weight incl. oil, gas, etc
|
138.0 kg (304.2 pounds) |
|
Seat height
|
818 mm (32.2 inches) If adjustable, lowest setting. |
|
Overall height
|
970 mm (38.2 inches) |
|
Overall length
|
2015 mm (79.3 inches) |
|
Overall width
|
660 mm (26.0 inches) |
|
Ground clearance
|
155 mm (6.1 inches) |
|
Wheelbase
|
1355 mm (53.3 inches) |
|
Fuel capacity
|
13.80 litres (3.65 US gallons) |
|
Oil capacity
|
1.20 litres (1.27 US quarts) |
|
Other specifications |
|
Color options
|
Grey, blue, white |
|
Starter
|
Electric |
