Yamaha's profilation of this bike |
With its explosive power delivery, low weight and super-agile handling performance, the Yamaha YZ125 2-stroke is one of the most exciting and rewarding dirt bikes you’ll ever ride. For even stronger performance the 125cc engine features a new combustion chamber shape as well as revised carburettor settings and a modified YPVS. |
General information |
Motorcycle name
|
Yamaha YZ 125 |
Year
|
2006 |
Category
|
Cross / motocross |
Rating
|
3.7 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
Engine and transmission |
Displacement
|
124.0 ccm (7.57 cubic inches) |
Engine type
|
Single cylinder, four-stroke |
Compression
|
8.6:1 |
Bore x stroke
|
54.0 x 54.5 mm (2.1 x 2.1 inches) |
Fuel system
|
Carburettor. Mikuni TMX38 |
Ignition
|
CDI |
Lubrication system
|
Premix |
Cooling system
|
Liquid |
Gearbox
|
5-speed |
Transmission type
|
Chain (final drive) |
Clutch
|
Wet, multiple-disc |
Chassis, suspension, brakes and wheels |
Front suspension
|
Telescopic fork |
Front wheel travel
|
300 mm (11.8 inches) |
Rear suspension
|
Swinging arm (link-type monocross) |
Rear wheel travel
|
125 mm (4.9 inches) |
Front tire
|
80/90-M21 |
Rear tire
|
100/90-M19 |
Front brakes
|
Single disc |
Diameter
|
250 mm (9.8 inches) |
Rear brakes
|
Single disc |
Diameter
|
245 mm (9.6 inches) |
Physical measures and capacities |
Dry weight
|
86.0 kg (189.6 pounds) |
Seat height
|
998 mm (39.3 inches) If adjustable, lowest setting. |
Overall height
|
1318 mm (51.9 inches) |
Overall length
|
2139 mm (84.2 inches) |
Overall width
|
827 mm (32.6 inches) |
Ground clearance
|
388 mm (15.3 inches) |
Wheelbase
|
1443 mm (56.8 inches) |
Fuel capacity
|
8.00 litres (2.11 US gallons) |
Other specifications |
Starter
|
Kick |
