General information |
|
Model
|
Yamaha YZ125 |
|
Model year
|
2013 |
|
Category
|
Cross / motocross |
| Price as new | US$ 6290. MSRP depends on country, taxes, accessories, etc. |
|
Rating
|
3.7 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
|
Engine and transmission |
|
Displacement
|
124.0 ccm (7.57 cubic inches) |
|
Engine type
|
Single cylinder, two-stroke |
|
Engine details
|
Reed-valve-inducted |
|
Compression
|
8.6:1 |
|
Bore x stroke
|
54.0 x 54.5 mm (2.1 x 2.1 inches) |
|
Fuel system
|
Carburettor. Mikuni TMX 38 |
|
Ignition
|
CDI |
|
Cooling system
|
Liquid |
|
Gearbox
|
6-speed |
|
Transmission type
|
Chain (final drive) |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Aluminum |
|
Rake (fork angle)
|
28.0° |
|
Front suspension
|
Speed-sensitive system inverted fork |
|
Front wheel travel
|
300 mm (11.8 inches) |
|
Rear suspension
|
Fully adjustable single shock |
|
Rear wheel travel
|
315 mm (12.4 inches) |
|
Rear tire
|
100/90-19 |
|
Front brakes
|
Single disc. Hydraulic disc. Hydraulic disc. |
|
Diameter
|
250 mm (9.8 inches) |
|
Rear brakes
|
Single disc |
|
Diameter
|
245 mm (9.6 inches) |
|
Physical measures and capacities |
|
Weight incl. oil, gas, etc
|
93.9 kg (207.0 pounds) |
|
Seat height
|
998 mm (39.3 inches) If adjustable, lowest setting. |
|
Overall height
|
1316 mm (51.8 inches) |
|
Overall length
|
2136 mm (84.1 inches) |
|
Overall width
|
828 mm (32.6 inches) |
|
Ground clearance
|
386 mm (15.2 inches) |
|
Wheelbase
|
1443 mm (56.8 inches) |
|
Fuel capacity
|
7.95 litres (2.10 US gallons) |
|
Other specifications |
|
Color options
|
Team Yamaha Blue/White |
|
Starter
|
Electric |
|
Factory warranty
|
30 Day (Limited Factory Warranty) |
