General information |
|
Model
|
Yamaha YX 600 Radian |
|
Model year
|
1986 |
|
Category
|
Naked bike |
| Price as new | US$ 2500. MSRP depends on country, taxes, accessories, etc. |
|
Rating
|
3.8 See the detailed rating of engine performance, design and look, accident risk, etc. Compare with any other motorcycle. |
|
Engine and transmission |
|
Displacement
|
599.0 ccm (36.55 cubic inches) |
|
Engine type
|
In-line four, four-stroke |
|
Power output
|
52.4 HP (38.3 kW)) @ 9000 RPM |
|
Torque
|
35.6 Nm (3.6 kgf-m or 26.3 ft.lbs) @ 7500 RPM |
|
Top speed
|
125.0 km/h (77.7 mph) |
|
0-100 km/h (0-62 mph)
|
3.76 seconds |
|
1/4 mile (0.4 km)
|
12.53 seconds |
|
60-140 km/h (37-87 mph), highest gear
|
6.48 seconds |
|
Max RPM
|
12000 |
|
Compression
|
10.0:1 |
|
Bore x stroke
|
58.5 x 55.7 mm (2.3 x 2.2 inches) |
|
Valves per cylinder
|
2 |
|
Fuel system
|
Carburettor. 4 mikuni BS30´s 30mm Constant Vacuum |
|
Fuel control
|
Double Overhead Cams/Twin Cam (DOHC) |
|
Ignition
|
TCI full transistor ignition |
|
Lubrication system
|
wet sump |
|
Cooling system
|
Air |
|
Gearbox
|
6-speed |
|
Transmission type
|
Chain (final drive) |
|
Clutch
|
wet plate |
|
Fuel consumption
|
5.10 litres/100 km (19.6 km/l or 46.12 mpg) |
|
Greenhouse gases
|
118.3 CO2 g/km. (CO2 - Carbon dioxide emission) |
|
Exhaust system
|
4 into 2 system |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
double downtube full cradle, box section steel wingarm |
|
Rake (fork angle)
|
27.0° |
|
Trail
|
128 mm (5.0 inches) |
|
Front suspension
|
36mm shocks |
|
Front wheel travel
|
140 mm (5.5 inches) |
|
Rear suspension
|
2 shock absorbers, adjustable for spring preload |
|
Rear wheel travel
|
98 mm (3.9 inches) |
|
Front tire
|
110/90-16 |
|
Rear tire
|
130/90-16 |
|
Front brakes
|
Double disc |
|
Rear brakes
|
Expanding brake (drum brake) |
|
Physical measures and capacities |
|
Weight incl. oil, gas, etc
|
197.8 kg (436.0 pounds) |
|
Seat height
|
765 mm (30.1 inches) If adjustable, lowest setting. |
|
Alternate seat height
|
765 mm (30.1 inches) If adjustable, highest setting. |
|
Overall height
|
1095 mm (43.1 inches) |
|
Overall length
|
2075 mm (81.7 inches) |
|
Overall width
|
770 mm (30.3 inches) |
|
Ground clearance
|
145 mm (5.7 inches) |
|
Wheelbase
|
1385 mm (54.5 inches) |
|
Fuel capacity
|
12.00 litres (3.17 US gallons) |
|
Reserve fuel capacity
|
2.50 litres (0.66 US gallons) |
|
Other specifications |
|
Color options
|
blue, red, black |
|
Starter
|
Electric |
| Update specs | Report missing specs or required updates. |
|
