Yamaha YBR125 20132013 Yamaha YBR125 specifications, pictures, reviews and rating |
| Yamaha's profilation of this bike |
| Built for easy-going performance and reliability, the YBR125 won´t let you down. |
| General information | |
|---|---|
| Motorcycle name | Yamaha YBR125 |
| Model year | 2013 |
| Category | Naked bike |
| Rating | 3.3 See the detailed rating of engine performance, design and look, accident risk, etc. Compare with any other motorcycle. |
| Engine and transmission | |
| Displacement | 124.0 ccm (7.57 cubic inches) |
| Engine type | Single cylinder, four-stroke |
| Engine details | Forward-inclined single cylinder |
| Power output | 10.1 HP (7.3 kW)) @ 10000 RPM |
| Torque | 9.6 Nm (1.0 kgf-m or 7.1 ft.lbs) @ 6000 RPM |
| Compression | 10.0:1 |
| Bore x stroke | 54.0 x 54.0 mm (2.1 x 2.1 inches) |
| Valves per cylinder | 2 |
| Fuel system | Injection. EFI |
| Fuel control | Single Overhead Cams (SOHC) |
| Ignition | TCI |
| Lubrication system | Wet sump |
| Cooling system | Air |
| Gearbox | 5-speed |
| Transmission type | Chain (final drive) |
| Clutch | Wet, multiple-disc coil spring |
| Driveline | Constant Mesh |
| Chassis, suspension, brakes and wheels | |
| Frame type | Steel, diamond shaped |
| Rake (fork angle) | 26.0° |
| Trail | 90 mm (3.5 inches) |
| Front suspension | Telescopic forks |
| Front wheel travel | 120 mm (4.7 inches) |
| Rear suspension | Swingarm |
| Rear wheel travel | 105 mm (4.1 inches) |
| Front tire | 2.75-18 |
| Rear tire | 90/90-18 |
| Front brakes | Single disc |
| Diameter | 245 mm (9.6 inches) |
| Rear brakes | Expanding brake (drum brake) |
| Diameter | 130 mm (5.1 inches) |
| Seat | Sculpted dual seat |
| Physical measures and capacities | |
| Weight incl. oil, gas, etc | 125.0 kg (275.6 pounds) |
| Seat height | 780 mm (30.7 inches) If adjustable, lowest setting. |
| Overall height | 1080 mm (42.5 inches) |
| Overall length | 1985 mm (78.1 inches) |
| Overall width | 745 mm (29.3 inches) |
| Ground clearance | 160 mm (6.3 inches) |
| Wheelbase | 1290 mm (50.8 inches) |
| Fuel capacity | 13.00 litres (3.43 US gallons) |
| Oil capacity | 1.20 litres (1.27 US quarts) |
| Other specifications | |
| Color options | Grey, red, black |
| Starter | Electric & kick |
| Instruments | Analogue instrument panel with RPM meter |
