Yamaha XV 1100 S Virago 19861986 Yamaha XV 1100 S Virago specifications, pictures, reviews and rating |
| General information | |
|---|---|
| Motorcycle name | Yamaha XV 1100 S Virago |
| Model year | 1986 |
| Category | Custom / cruiser |
| Rating | 3.5 See the detailed rating of design and look, maintenance cost, engine performance, etc. Compare with any other bike. |
| Engine and transmission | |
| Displacement | 1063.0 ccm (64.86 cubic inches) |
| Engine type | V2, four-stroke |
| Power output | 55.0 HP (40.1 kW)) |
| Top speed | 160.0 km/h (99.4 mph) |
| Max RPM | 7000 |
| Compression | 8.3:1 |
| Bore x stroke | 95.0 x 75.0 mm (3.7 x 3.0 inches) |
| Valves per cylinder | 2 |
| Fuel system | Carburettor. Hitachi HSC40 |
| Ignition | Fullytransistorized.Fixed |
| Lubrication system | Oil pump |
| Cooling system | Air |
| Gearbox | 5-speed |
| Transmission type | Shaft drive (cardan) (final drive) |
| Clutch | Wet, multi-plate |
| Chassis, suspension, brakes and wheels | |
| Front tire | 100/90-19 57H |
| Rear tire | 140/90-15 70H |
| Front brakes | Double disc. 2-piston calipers |
| Rear brakes | Expanding brake (drum brake) |
| Physical measures and capacities | |
| Weight incl. oil, gas, etc | 245.0 kg (540.1 pounds) |
| Overall length | 2320 mm (91.3 inches) |
| Overall width | 880 mm (34.6 inches) |
| Fuel capacity | 16.00 litres (4.23 US gallons) |
| Reserve fuel capacity | 3.00 litres (0.79 US gallons) |
| Other specifications | |
| Starter | Electric |
