Yamaha's profilation of this bike |
Large wheels and ABS give you the added stability and control you need. Add extensive weather protection, a large and comfy double seat plus storage space for two helmets, and the X-MAX 125 is a perfect combination of modern design and practicality. |
General information |
Motorcycle name
|
Yamaha X-Max 125 ABS |
Year
|
2011 |
Category
|
Scooter |
Rating
|
Do you know this bike? Click here to rate it. We miss 2 votes to show the rating. |
Engine and transmission |
Displacement
|
124.7 ccm (7.61 cubic inches) |
Engine type
|
Single cylinder, four-stroke |
Power
|
14.0 HP (10.2 kW)) |
Torque
|
11.3 Nm (1.2 kgf-m or 8.4 ft.lbs) @ 8750 RPM |
Bore x stroke
|
52.0 x 58.6 mm (2.0 x 2.3 inches) |
Fuel system
|
Injection |
Ignition
|
TCI |
Lubrication system
|
Wet sump |
Cooling system
|
Liquid |
Gearbox
|
Automatic |
Transmission type
|
Belt (final drive) |
Chassis, suspension, brakes and wheels |
Frame type
|
Steel |
Front suspension
|
Telescopic fork |
Front wheel travel
|
110 mm (4.3 inches) |
Rear suspension
|
Unit Swing |
Front tire
|
120/70-15 |
Rear tire
|
140/70-14 |
Front brakes
|
Single disc. Anti-lock braking |
Diameter
|
267 mm (10.5 inches) |
Rear brakes
|
Single disc. Anti-lock braking |
Diameter
|
240 mm (9.4 inches) |
Seat
|
dual seat |
Physical measures and capacities |
Weight incl. oil, gas, etc
|
176.0 kg (388.0 pounds) |
Seat height
|
792 mm (31.2 inches) If adjustable, lowest setting. |
Overall height
|
1337 mm (52.6 inches) |
Overall length
|
2200 mm (86.6 inches) |
Overall width
|
776 mm (30.6 inches) |
Ground clearance
|
135 mm (5.3 inches) |
Wheelbase
|
1545 mm (60.8 inches) |
Fuel capacity
|
11.80 litres (3.12 US gallons) |
Other specifications |
Color options
|
Red, white, black |
Starter
|
Electric |
Carrying capacity
|
Underseat storage for two full-face helmets. |
