General moped information |
|
Model
|
Yamaha Vox Deluxe |
|
Year of manufacture
|
2011 |
|
Type
|
Scooter |
|
Rating
|
3.3 View the detailed rating of value for money, design and look, reliability, etc. Compare with any other bike. |
|
Engine and transmission |
|
Engine size
|
49.0 ccm (2.99 cubic inches) |
|
Type of engine
|
Single cylinder, four-stroke |
|
Output
|
4.2 HP (3.0 kW)) @ 8000 RPM |
|
Torque
|
3.9 Nm (0.4 kgf-m or 2.9 ft.lbs) @ 6500 RPM |
|
Compression
|
12.0:1 |
|
Bore x stroke
|
38.0 x 43.5 mm (1.5 x 1.7 inches) |
|
Valves per cylinder
|
3 |
|
Fuel system
|
Injection |
|
Fuel control
|
Single Overhead Cams (SOHC) |
|
Ignition
|
TCI |
|
Lubrication system
|
Forced by pump |
|
Cooling system
|
Air |
|
Gearbox
|
Automatic |
|
Transmission type
|
Belt (final drive) |
|
Clutch
|
Automatic centrifugal |
|
Driveline
|
V belt type continuously variable transmission |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Backbone pipe |
|
Rake (fork angle)
|
26.0° |
|
Trail
|
84 mm (3.3 inches) |
|
Front suspension
|
Telescopic |
|
Rear suspension
|
Swing unit |
|
Front tire
|
120/90-10 |
|
Rear tire
|
120/90-10 |
|
Front brakes
|
Expanding brake (drum brake) |
|
Rear brakes
|
Expanding brake (drum brake) |
|
Physical measures and capacities |
|
Dry weight
|
90.0 kg (198.4 pounds) |
|
Weight incl. oil, gas, etc
|
95.0 kg (209.4 pounds) |
|
Power/weight ratio
|
0.0462 HP/kg |
|
Seat height
|
735 mm (28.9 inches) If adjustable, lowest setting. |
|
Overall height
|
1045 mm (41.1 inches) |
|
Overall length
|
1855 mm (73.0 inches) |
|
Overall width
|
685 mm (27.0 inches) |
|
Ground clearance
|
115 mm (4.5 inches) |
|
Wheelbase
|
1280 mm (50.4 inches) |
|
Fuel capacity
|
4.50 litres (1.19 US gallons) |
|
Other specifications |
|
Color options
|
Brown, white, black |
|
Starter
|
Electric |
