General information |
|
Model
|
Yamaha TT-R 125 LW |
|
Model year
|
2002 |
|
Category
|
Cross / motocross |
|
Rating
|
3.4 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
|
Engine and transmission |
|
Displacement
|
123.7 ccm (7.55 cubic inches) |
|
Engine type
|
Single cylinder, four-stroke |
|
Power output
|
9.8 HP (7.2 kW)) @ 8000 RPM |
|
Torque
|
9.9 Nm (1.0 kgf-m or 7.3 ft.lbs) @ 6500 RPM |
|
Compression
|
10.0:1 |
|
Bore x stroke
|
54.0 x 54.0 mm (2.1 x 2.1 inches) |
|
Fuel control
|
Single Overhead Cams (SOHC) |
|
Cooling system
|
Air |
|
Chassis, suspension, brakes and wheels |
|
Front wheel travel
|
180 mm (7.1 inches) |
|
Rear wheel travel
|
168 mm (6.6 inches) |
|
Front tire
|
70/100-19 |
|
Rear tire
|
90/100-15 |
|
Front brakes
|
Expanding brake |
|
Diameter
|
220 mm (8.7 inches) |
|
Rear brakes
|
Expanding brake |
|
Diameter
|
110 mm (4.3 inches) |
|
Physical measures and capacities |
|
Dry weight
|
78.0 kg (172.0 pounds) |
|
Power/weight ratio
|
0.1256 HP/kg |
|
Seat height
|
805 mm (31.7 inches) If adjustable, lowest setting. |
|
Overall height
|
1085 mm (42.7 inches) |
|
Overall length
|
1885 mm (74.2 inches) |
|
Overall width
|
795 mm (31.3 inches) |
|
Ground clearance
|
295 mm (11.6 inches) |
|
Wheelbase
|
1270 mm (50.0 inches) |
|
