Yamaha's profilation of this bike |
Everything about this rider-friendly mini-bike is designed to create a fun and enjoyable experience for riders between 4 and 7 years of age. For simple riding, the electric-start 50cc 4-stroke engine is equipped with a semi-automatic 3-speed gearbox - and for added parental control the TT-R50E can only be started with the ignition key inserted. |
General moped information |
Model name
|
Yamaha TT-R50E |
Year of manufacture
|
2011 |
Type
|
Minibike, cross |
Rating
|
2.9 See the detailed rating of the fun-factor, engine performance, racing track capabilities, etc. Compare with any other bike. |
Engine and transmission |
Engine size
|
49.0 ccm (2.99 cubic inches) |
Type of engine
|
Single cylinder, four-stroke |
Compression
|
9.5:1 |
Bore x stroke
|
36.0 x 48.6 mm (1.4 x 1.9 inches) |
Valves per cylinder
|
2 |
Fuel system
|
Carburettor. Mikuni® VM11 |
Fuel control
|
Single Overhead Cams (SOHC) |
Ignition
|
CDI |
Cooling system
|
Air |
Gearbox
|
3-speed |
Transmission type
|
Chain (final drive) |
Clutch
|
Automatic |
Chassis, suspension, brakes and wheels |
Front suspension
|
Inverted telescopic fork |
Front wheel travel
|
97 mm (3.8 inches) |
Rear suspension
|
Single shock |
Rear wheel travel
|
71 mm (2.8 inches) |
Front brakes
|
Expanding brake (drum brake) |
Rear brakes
|
Expanding brake (drum brake) |
Physical measures and capacities |
Weight incl. oil, gas, etc
|
56.7 kg (125.0 pounds) |
Seat height
|
554 mm (21.8 inches) If adjustable, lowest setting. |
Overall height
|
775 mm (30.5 inches) |
Overall length
|
1306 mm (51.4 inches) |
Overall width
|
594 mm (23.4 inches) |
Ground clearance
|
135 mm (5.3 inches) |
Wheelbase
|
925 mm (36.4 inches) |
Fuel capacity
|
3.00 litres (0.79 US gallons) |
Other specifications |
Color options
|
Team Yamaha Blue/White |
Starter
|
Electric |
Comments
|
Intended for kids from 4 to 7 years of age. |
