2013 Yamaha TMAX

Yamaha TMAX 2013


2013 Yamaha TMAX specifications, pictures, reviews and rating

Yamaha's profilation of this bike
Fuel-injected, liquid-cooled, four-valve-per-cylinder engine boasts forged pistons, carburized connecting rods, and ceramic-composite plated cylinders. The TMAX has a 11.0:1 compression ratio; upswept muffler canister; Controlled-fill die-cast aluminum frame; 43mm front forks; 4-piston mono-block caliper dual front disc brakes; rear disc brake; aluminum die cast wheels with radial H-rated tires; fully featured multifunction instrumentation with speedometer and tachometer; and radical new sports styling; with those credentials, it’s no wonder TMAX is the Super Sport Scooter.

General information
Model name Yamaha TMAX
Year 2013
Category Scooter
Price as newUS$ 8590. MSRP depends on country, taxes, accessories, etc.
Rating 2.0  View the detailed rating of value for money, design and look, reliability, etc. Compare with any other bike.
Engine and transmission
Displacement 499.0 ccm (30.45 cubic inches)
Engine type Twin, four-stroke
Engine details Forward inclined parallel cylinders
Compression 11.0:1
Bore x stroke 66.0 x 73.0 mm (2.6 x 2.9 inches)
Valves per cylinder 4
Fuel system Injection. Electronic fuel injection
Fuel control Double Overhead Cams/Twin Cam (DOHC)
Ignition Digital TCI: Transistor Controlled Ignition
Cooling system Liquid
Transmission type Belt (final drive)
Clutch Wet, multiple-disc automatic centrifugal
Driveline V-belt
Fuel consumption 5.00 litres/100 km (20.0 km/l or 47.04 mpg)
Greenhouse gases 116.0 CO2 g/km. (CO2 - Carbon dioxide emission)
Chassis, suspension, brakes and wheels
Front suspension 43mm telescopic forks
Rear suspension Swingarm
Front tire 120/70-H15
Rear tire 160/60-H15
Front brakes Single disc
Diameter 267 mm (10.5 inches)
Rear brakes Single disc
Diameter 267 mm (10.5 inches)
Physical measures and capacities
Weight incl. oil, gas, etc 221.8 kg (489.0 pounds)
Seat height 800 mm (31.5 inches) If adjustable, lowest setting.
Overall height 1445 mm (56.9 inches)
Overall length 2195 mm (86.4 inches)
Overall width 775 mm (30.5 inches)
Ground clearance 124 mm (4.9 inches)
Wheelbase 1580 mm (62.2 inches)
Fuel capacity 15.14 litres (4.00 US gallons)
Other specifications
Color options Raven
Starter Electric
Factory warranty 1 Year (Limited Factory Warranty)
