Yamaha's profilation of this bike |
Are you ready for the New 2004 Road Star? The Star Family´s bare-knuckled brawler has been working out hard and it shows - inside and out. Modern-day V-twin muscle meets legendary styling, making this more than just a motorcycle. It´s a rolling work of art.
|
General information |
Model name
|
Yamaha Road Star 1700 |
Model year
|
2005 |
Category
|
Custom / cruiser |
Price as new | US$ 11099. MSRP depends on country, taxes, accessories, etc. |
Rating
|
3.7 See the detailed rating of design and look, maintenance cost, engine performance, etc. Compare with any other bike. |
Engine and transmission |
Displacement
|
1670.0 ccm (101.90 cubic inches) |
Engine type
|
V2, four-stroke |
Compression
|
8.3:1 |
Bore x stroke
|
97.0 x 113.0 mm (3.8 x 4.4 inches) |
Fuel system
|
Carburettor |
Fuel control
|
Overhead Valves (OHV) |
Cooling system
|
Air |
Gearbox
|
5-speed |
Transmission type
|
Belt (final drive) |
Chassis, suspension, brakes and wheels |
Frame type
|
Aluminium |
Front suspension
|
43mm Telescopic fork with adjustable preload; 5.5´ travel |
Rear suspension
|
Single shock, link-type; 4.3´ travel |
Front tire
|
130/90-16 |
Rear tire
|
150/80-16 |
Front brakes
|
Double disc |
Diameter
|
298 mm (11.7 inches) |
Rear brakes
|
Single disc |
Diameter
|
320 mm (12.6 inches) |
Physical measures and capacities |
Seat height
|
709 mm (27.9 inches) If adjustable, lowest setting. |
Overall length
|
2499 mm (98.4 inches) |
Wheelbase
|
1689 mm (66.5 inches) |
Fuel capacity
|
20.06 litres (5.30 US gallons) |
Other specifications |
Color options
|
Raven/Raspberry Metallic; Pearl White |
Update specs | Report missing specs or required updates. |
