General information |
Model name
|
Yamaha RD 350 |
Year
|
1980 |
Category
|
Sport touring |
Rating
|
4.1 See the detailed rating of touring capabilities, reliability, accident risk, etc. Compare with any other motorbike. |
Engine and transmission |
Displacement
|
347.0 ccm (21.17 cubic inches) |
Engine type
|
Twin, two-stroke |
Power
|
47.0 HP (34.3 kW)) @ 8700 RPM |
Torque
|
40.2 Nm (4.1 kgf-m or 29.7 ft.lbs) @ 4100 RPM |
Top speed
|
178.0 km/h (110.6 mph) |
Compression
|
6.9:1 |
Bore x stroke
|
64.0 x 54.0 mm (2.5 x 2.1 inches) |
Fuel system
|
Carburettor |
Fuel control
|
Membrane |
Ignition
|
Flywheel magneto CDI |
Lubrication system
|
Autolube |
Cooling system
|
Air |
Gearbox
|
6-speed |
Transmission type
|
Chain (final drive) |
Clutch
|
Wet multiplate |
Fuel consumption
|
5.47 litres/100 km (18.3 km/l or 43.00 mpg) |
Greenhouse gases
|
126.9 CO2 g/km. (CO2 - Carbon dioxide emission) |
Chassis, suspension, brakes and wheels |
Frame type
|
Tubular steel, double front downtubes |
Front suspension
|
32mm stanchion tube forks |
Rear suspension
|
Single shock cantilever, 5-way adjustable spring preload |
Front tire
|
3.00-18 |
Rear tire
|
3.50-18 |
Front brakes
|
Double disc. 0 |
Diameter
|
267 mm (10.5 inches) |
Rear brakes
|
Expanding brake |
Physical measures and capacities |
Dry weight
|
143.0 kg (315.3 pounds) |
Weight incl. oil, gas, etc
|
150.0 kg (330.7 pounds) |
Power/weight ratio
|
0.3287 HP/kg |
Seat height
|
785 mm (30.9 inches) If adjustable, lowest setting. |
Overall length
|
2080 mm (81.9 inches) |
Ground clearance
|
165 mm (6.5 inches) |
Wheelbase
|
1365 mm (53.7 inches) |
Fuel capacity
|
17.00 litres (4.49 US gallons) |
Other specifications |
Starter
|
Kick |
