Yamaha's profilation of this bike |
Take the driving seat and you´ll see that the JogR is a featherweight wonder. Its assymetric frame is light, strong and rigid, providing agile handling and easy manoeuvrability. |
General moped information |
Model
|
Yamaha Jog R |
Year
|
2011 |
Category
|
Scooter |
Rating
|
3.3 View the detailed rating of value for money, design and look, reliability, etc. Compare with any other bike. |
Engine and transmission |
Displacement
|
49.0 ccm (2.99 cubic inches) |
Engine type
|
Single cylinder, two-stroke |
Power
|
2.7 HP (2.0 kW)) @ 7000 RPM |
Torque
|
2.5 Nm (0.3 kgf-m or 1.8 ft.lbs) @ 7000 RPM |
Compression
|
11.6:1 |
Bore x stroke
|
40.0 x 39.2 mm (1.6 x 1.5 inches) |
Fuel system
|
Carburettor |
Fuel control
|
Single Overhead Cams (SOHC) |
Ignition
|
CDI |
Lubrication system
|
Separate lubrication |
Cooling system
|
Air |
Gearbox
|
Automatic |
Transmission type
|
Belt (final drive) |
Chassis, suspension, brakes and wheels |
Front suspension
|
Telescopic fork |
Front wheel travel
|
70 mm (2.8 inches) |
Rear suspension
|
Unit Swing |
Front tire
|
110/70-12 |
Rear tire
|
120/70-12 |
Front brakes
|
Single disc |
Diameter
|
190 mm (7.5 inches) |
Rear brakes
|
Expanding brake (drum brake) |
Diameter
|
110 mm (4.3 inches) |
Physical measures and capacities |
Weight incl. oil, gas, etc
|
81.0 kg (178.6 pounds) |
Seat height
|
770 mm (30.3 inches) If adjustable, lowest setting. |
Overall height
|
1065 mm (41.9 inches) |
Overall length
|
1740 mm (68.5 inches) |
Overall width
|
675 mm (26.6 inches) |
Ground clearance
|
132 mm (5.2 inches) |
Wheelbase
|
1210 mm (47.6 inches) |
Fuel capacity
|
5.50 litres (1.45 US gallons) |
Other specifications |
Color options
|
White/red, white/grey |
Starter
|
Electric & kick |
