General moped information |
|
Model
|
Yamaha Jog |
|
Model year
|
2012 |
|
Category
|
Scooter |
|
Rating
|
Do you know this bike?
Click here to rate it. We miss 1 vote to show the rating. |
|
Engine and transmission |
|
Displacement
|
49.0 ccm (2.99 cubic inches) |
|
Engine type
|
Single cylinder, two-stroke |
|
Engine details
|
Reed valve |
|
Compression
|
7.3:1 |
|
Bore x stroke
|
40.0 x 39.2 mm (1.6 x 1.5 inches) |
|
Fuel system
|
Carburettor. Gurtner 12mm |
|
Ignition
|
CDI |
|
Lubrication system
|
Yamaha Autolube |
|
Cooling system
|
Liquid |
|
Gearbox
|
Automatic |
|
Transmission type
|
Belt (final drive) |
|
Chassis, suspension, brakes and wheels |
|
Front suspension
|
Telescopic hydraulic fork |
|
Rear suspension
|
Swingarm w/ hydraulic single shock |
|
Front tire
|
90/90-10 |
|
Rear tire
|
90/90-10 |
|
Front brakes
|
Single disc |
|
Rear brakes
|
Expanding brake (drum brake) |
|
Wheels
|
Three-spoke wheels |
|
Physical measures and capacities |
|
Weight incl. oil, gas, etc
|
74.0 kg (163.1 pounds) |
|
Seat height
|
710 mm (28.0 inches) If adjustable, lowest setting. |
|
Overall height
|
1005 mm (39.6 inches) |
|
Overall length
|
1670 mm (65.7 inches) |
|
Overall width
|
640 mm (25.2 inches) |
|
Ground clearance
|
85 mm (3.3 inches) |
|
Wheelbase
|
1160 mm (45.7 inches) |
|
Fuel capacity
|
6.00 litres (1.59 US gallons) |
|
Other specifications |
|
Color options
|
Black, blue, silver |
|
Starter
|
Electric & kick |
|
Carrying capacity
|
Underseat lockable storage |
