General information |
|
Motorcycle name
|
Yamaha DT 175 MX |
|
Year
|
1979 |
|
Category
|
Enduro / offroad |
|
Rating
|
3.3 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
|
Engine and transmission |
|
Displacement
|
171.0 ccm (10.43 cubic inches) |
|
Engine type
|
Single cylinder, two-stroke |
|
Engine details
|
Reed valve. |
|
Power
|
15.0 HP (10.9 kW)) @ 7500 RPM |
|
Torque
|
8.8 Nm (0.9 kgf-m or 6.5 ft.lbs) @ 6000 RPM |
|
Top speed
|
115.0 km/h (71.5 mph) |
|
Compression
|
6.8:1 |
|
Bore x stroke
|
66.0 x 50.0 mm (2.6 x 2.0 inches) |
|
Fuel system
|
Carburettor |
|
Fuel control
|
Membrane |
|
Ignition
|
CDI, magneto type |
|
Cooling system
|
Air |
|
Gearbox
|
6-speed |
|
Transmission type
|
Chain (final drive) |
|
Clutch
|
Wet, multiplate type |
|
Driveline
|
DID428SM chain, 117 links |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Welded, tubular, double cradle with single downtube |
|
Trail
|
60 mm (2.4 inches) |
|
Front suspension
|
Telescopic, oil damped |
|
Rear suspension
|
Dual shocks |
|
Front tire
|
2.75-21 |
|
Rear tire
|
3.50-18 |
|
Front brakes
|
Expanding brake (drum brake) |
|
Rear brakes
|
Expanding brake |
|
Physical measures and capacities |
|
Dry weight
|
99.0 kg (218.3 pounds) |
|
Weight incl. oil, gas, etc
|
111.0 kg (244.7 pounds) |
|
Power/weight ratio
|
0.1515 HP/kg |
|
Seat height
|
845 mm (33.3 inches) If adjustable, lowest setting. |
|
Overall length
|
2080 mm (81.9 inches) |
|
Ground clearance
|
265 mm (10.4 inches) |
|
Wheelbase
|
1350 mm (53.1 inches) |
|
Fuel capacity
|
7.00 litres (1.85 US gallons) |
|
Other specifications |
|
Starter
|
Kick |
|
Electrical
|
6V, 4Ah battery. |
