General information |
|
Motorcycle name
|
Yamaha Drag Star Four |
|
Year
|
2002 |
|
Category
|
Custom / cruiser |
|
Rating
|
3.6 See the detailed rating of design and look, maintenance cost, engine performance, etc. Compare with any other bike. |
|
Engine and transmission |
|
Displacement
|
399.0 ccm (24.35 cubic inches) |
|
Engine type
|
V2, four-stroke |
|
Power
|
32.0 HP (23.4 kW)) @ 7500 RPM |
|
Torque
|
32.0 Nm (3.3 kgf-m or 23.6 ft.lbs) @ 6000 RPM |
|
Compression
|
9.7:1 |
|
Bore x stroke
|
68.0 x 55.0 mm (2.7 x 2.2 inches) |
|
Valves per cylinder
|
2 |
|
Fuel system
|
Carburettor |
|
Fuel control
|
Single Overhead Cams (SOHC) |
|
Cooling system
|
Air |
|
Gearbox
|
5-speed |
|
Transmission type
|
Shaft drive (cardan) (final drive) |
|
Chassis, suspension, brakes and wheels |
|
Front tire
|
100/90-19 57S |
|
Rear tire
|
170/80-15 M/C 77S |
|
Front brakes
|
Single disc |
|
Rear brakes
|
Expanding brake |
|
Physical measures and capacities |
|
Dry weight
|
209.0 kg (460.8 pounds) |
|
Power/weight ratio
|
0.1531 HP/kg |
|
Seat height
|
660 mm (26.0 inches) If adjustable, lowest setting. |
|
Overall height
|
1060 mm (41.7 inches) |
|
Overall length
|
2340 mm (92.1 inches) |
|
Overall width
|
840 mm (33.1 inches) |
|
Ground clearance
|
140 mm (5.5 inches) |
|
Wheelbase
|
1610 mm (63.4 inches) |
|
Fuel capacity
|
15.00 litres (3.96 US gallons) |
|
