Yamaha Drag Star Four 20022002 Yamaha Drag Star Four specifications, pictures, reviews and rating |
| General information | |
|---|---|
| Motorcycle name | Yamaha Drag Star Four |
| Year | 2002 |
| Category | Custom / cruiser |
| Rating | 3.6 See the detailed rating of design and look, maintenance cost, engine performance, etc. Compare with any other bike. |
| Engine and transmission | |
| Displacement | 399.0 ccm (24.35 cubic inches) |
| Engine type | V2, four-stroke |
| Power | 32.0 HP (23.4 kW)) @ 7500 RPM |
| Torque | 32.0 Nm (3.3 kgf-m or 23.6 ft.lbs) @ 6000 RPM |
| Compression | 9.7:1 |
| Bore x stroke | 68.0 x 55.0 mm (2.7 x 2.2 inches) |
| Valves per cylinder | 2 |
| Fuel system | Carburettor |
| Fuel control | Single Overhead Cams (SOHC) |
| Cooling system | Air |
| Gearbox | 5-speed |
| Transmission type | Shaft drive (cardan) (final drive) |
| Chassis, suspension, brakes and wheels | |
| Front tire | 100/90-19 57S |
| Rear tire | 170/80-15 M/C 77S |
| Front brakes | Single disc |
| Rear brakes | Expanding brake |
| Physical measures and capacities | |
| Dry weight | 209.0 kg (460.8 pounds) |
| Power/weight ratio | 0.1531 HP/kg |
| Seat height | 660 mm (26.0 inches) If adjustable, lowest setting. |
| Overall height | 1060 mm (41.7 inches) |
| Overall length | 2340 mm (92.1 inches) |
| Overall width | 840 mm (33.1 inches) |
| Ground clearance | 140 mm (5.5 inches) |
| Wheelbase | 1610 mm (63.4 inches) |
| Fuel capacity | 15.00 litres (3.96 US gallons) |
| Other specifications | |
| Update specs | Report missing specs or required updates. |
| Further information | |
| Insurance costs | Compare US insurance quotes from the nation's top providers. |
| Parts finder | CMSNL provides
online schematics & OEM parts |
| Maintenance | Find parts, fluids. filters, maintenance tools and service manuals at Amazon.com. |
| Ask questions | Join the 02 Yamaha Drag Star Four discussion group or the general Yamaha discussion group. |
| Related bikes | List related bikes for comparison of specs. |
| Compare with another motorcycle | |
