Yamaha BWs Naked 50 20132013 Yamaha BWs Naked 50 specifications, pictures, reviews and rating |
 2013 Yamaha BWs Naked 50. Picture credits - Yamaha. Submit more pictures.
|
| Yamaha's profilation of this bike |
| The BW’s Naked is your kind of machine: all of the fun of the original BW’s, but with everything else stripped right back. What you’re left with is unique styling and the freedom of pure riding fun. |
| General moped information | |
|---|---|
| Motorcycle name | Yamaha BWs Naked 50 |
| Model year | 2013 |
| Category | Scooter |
| Rating |
Do you know this bike? Click here to rate it. We miss 2 votes to show the rating. |
| Engine and transmission | |
| Displacement | 49.2 ccm (3.00 cubic inches) |
| Engine type | Single cylinder, two-stroke |
| Power output | 3.2 HP (2.4 kW)) @ 6500 RPM |
| Torque | 3.6 Nm (0.4 kgf-m or 2.7 ft.lbs) @ 6000 RPM |
| Compression | 7.2:1 |
| Bore x stroke | 40.0 x 39.2 mm (1.6 x 1.5 inches) |
| Fuel system | Carburettor |
| Ignition | CDI |
| Lubrication system | Separate lubrication |
| Cooling system | Air |
| Gearbox | Automatic |
| Transmission type | Belt (final drive) |
| Chassis, suspension, brakes and wheels | |
| Frame type | Steel |
| Front suspension | Telescopic fork |
| Front wheel travel | 70 mm (2.8 inches) |
| Rear suspension | Unit swing |
| Rear wheel travel | 70 mm (2.8 inches) |
| Front tire | 120/90-10 |
| Rear tire | 150/80-10 |
| Front brakes | Single disc |
| Diameter | 180 mm (7.1 inches) |
| Rear brakes | Expanding brake (drum brake) |
| Diameter | 110 mm (4.3 inches) |
| Wheels | Alloy wheels |
| Seat | Dual seat with passenger grab handles |
| Physical measures and capacities | |
| Dry weight | 83.0 kg (183.0 pounds) |
| Power/weight ratio | 0.0388 HP/kg |
| Seat height | 768 mm (30.2 inches) If adjustable, lowest setting. |
| Overall height | 1052 mm (41.4 inches) |
| Overall length | 1685 mm (66.3 inches) |
| Overall width | 690 mm (27.2 inches) |
| Ground clearance | 120 mm (4.7 inches) |
| Wheelbase | 1152 mm (45.4 inches) |
| Fuel capacity | 5.30 litres (1.40 US gallons) |
| Other specifications | |
| Color options | Red, grey |
| Starter | Electric & kick |
| Light | twin headlights |
| Modifications compared to previous model | Compact, new instrument pod. |
| Update specs | Report missing specs or required updates. |
