General information |
|
Motorcycle name
|
WSK 175 W21B2S2 |
|
Model year
|
1977 |
|
Category
|
Enduro / offroad |
|
Rating
|
3.2 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
|
Engine and transmission |
|
Displacement
|
173.8 ccm (10.61 cubic inches) |
|
Engine type
|
Single cylinder, two-stroke |
|
Power output
|
14.0 HP (10.2 kW)) @ 6300 RPM |
|
Torque
|
16.7 Nm (1.7 kgf-m or 12.3 ft.lbs) @ 5800 RPM |
|
Top speed
|
100.0 km/h (62.1 mph) |
|
Max RPM
|
6600 |
|
Compression
|
9.0:1 |
|
Bore x stroke
|
61.0 x 59.5 mm (2.4 x 2.3 inches) |
|
Fuel system
|
Carburettor. Bing 1/26/125/II 26 mm |
|
Fuel control
|
Port control |
|
Ignition
|
Magneto |
|
Lubrication system
|
Mixture 1 : 30 |
|
Cooling system
|
Air |
|
Gearbox
|
4-speed |
|
Transmission type
|
Chain (final drive) |
|
Clutch
|
Wet 4 plate |
|
Fuel consumption
|
3.00 litres/100 km (33.3 km/l or 78.41 mpg) |
|
Greenhouse gases
|
69.6 CO2 g/km. (CO2 - Carbon dioxide emission) |
|
Exhaust system
|
Steel single pipe |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Single, steel welded tubes |
|
Front suspension
|
Coil springs with oil shock absorbers in fork |
|
Front wheel travel
|
150 mm (5.9 inches) |
|
Rear suspension
|
Trailing arms with two coil springs and oil shock absorbers |
|
Front tire
|
3.00-19 |
|
Rear tire
|
3.00-18 |
|
Front brakes
|
Expanding brake (drum brake) |
|
Diameter
|
135 mm (5.3 inches) |
|
Rear brakes
|
Expanding brake (drum brake) |
|
Diameter
|
135 mm (5.3 inches) |
|
Physical measures and capacities |
|
Dry weight
|
111.0 kg (244.7 pounds) |
|
Power/weight ratio
|
0.1261 HP/kg |
|
Overall height
|
1080 mm (42.5 inches) |
|
Overall length
|
2020 mm (79.5 inches) |
|
Overall width
|
860 mm (33.9 inches) |
|
Wheelbase
|
1320 mm (52.0 inches) |
|
Fuel capacity
|
8.00 litres (2.11 US gallons) |
|
Reserve fuel capacity
|
2.00 litres (0.53 US gallons) |
|
Other specifications |
|
Color options
|
Orange only |
|
Starter
|
Kick |
|
Modifications compared to previous model
|
Face lifting of W21B2S1. |
