General information |
|
Model name
|
Wakan Road |
|
Year of manufacture
|
2008 |
|
Type
|
Naked bike |
|
Rating
|
Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
|
Engine and transmission |
|
Engine size
|
1640.0 ccm (100.07 cubic inches) |
|
Type of engine
|
V2, four-stroke |
|
Output
|
115.0 HP (83.9 kW)) @ 6250 RPM |
|
Torque
|
115.0 Nm (11.7 kgf-m or 84.8 ft.lbs) @ 4250 RPM |
|
Top speed
|
250.0 km/h (155.3 mph) |
|
Compression
|
10.3:1 |
|
Fuel system
|
Carburettor. 1 x 41 mm Keihin FCR flatslide downdraft. |
|
Fuel control
|
Overhead Valves (OHV) |
|
Ignition
|
CDI |
|
Cooling system
|
Air |
|
Gearbox
|
5-speed |
|
Transmission type
|
Belt (final drive) |
|
Clutch
|
Multiplate dry,7 steel/7, with hydraulic drive. |
|
Exhaust system
|
2 into 1 into 2 silencers. |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
TIG-welded chrome-moly steel tubular backbone frame |
|
Rake (fork angle)
|
22.0° |
|
Trail
|
83 mm (3.3 inches) |
|
Front suspension
|
46 mm Ceriani Italy inverted fully adjustable forks. |
|
Rear suspension
|
Extruded aluminium swingarm with ZF Sachs shock. |
|
Front tire
|
120/70-ZR17 |
|
Rear tire
|
180/55-ZR17 |
|
Front brakes
|
Single disc |
|
Diameter
|
340 mm (13.4 inches) |
|
Rear brakes
|
Single disc |
|
Diameter
|
220 mm (8.7 inches) |
|
Physical measures and capacities |
|
Dry weight
|
177.0 kg (390.2 pounds) |
|
Power/weight ratio
|
0.6497 HP/kg |
|
Seat height
|
790 mm (31.1 inches) If adjustable, lowest setting. |
|
Wheelbase
|
1370 mm (53.9 inches) |
|
Fuel capacity
|
13.00 litres (3.43 US gallons) |
|
Other specifications |
|
Color options
|
Red, black |
|
Starter
|
Electric |
