| VOR's profilation of this bike |
| This limited edition, powered by the exclusive and competitive 570cc unit, is based on the evolution of the last year VOR’s factory bikes ridden in the championships just over.
|
| General information |
|---|
| Model: | VOR SM-RC 570 Supermotard |
| Year: | 2007 |
| Category: | Super motard |
| Rating: | 3.5 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
| Engine and transmission |
|---|
| Displacement: | 569.0 ccm (34.72 cubic inches) |
| Engine type: | Single cylinder, four-stroke |
| Compression: | 11.0:1 |
| Bore x stroke: | 97.0 x 71.0 mm (3.8 x 2.8 inches) |
| Valves per cylinder: | 4 |
| Fuel system: | Carburettor. Keihin FCR 41 |
| Fuel control: | Single Overhead Cams (SOHC) |
| Ignition: | SEM electronic |
| Cooling system: | Liquid |
| Gearbox: | 5-speed |
Transmission type,
final drive: | Chain |
| Clutch: | Discs in oil bath, hydraulic control |
| Chassis, suspension, brakes and wheels |
|---|
| Frame type: | Perimeter in molybdenum chrome-plated steel. Rear mini-frame in aluminium. |
| Front suspension: | Fork with inverted ø 46 mm rods. Pre-loading, extension, compression |
| Front wheel travel: | 275 mm (10.8 inches) |
| Rear suspension: | Single shock absorber on graduated system. Pre-loading adjustment, extension, compression |
| Rear wheel travel: | 275 mm (10.8 inches) |
| Front tyre: | 120/70-17 |
| Rear tyre: | 160/60-17 |
| Front brakes: | Single disc |
| Diameter: | 320 mm (12.6 inches) |
| Rear brakes: | Single disc |
| Diameter: | 220 mm (8.7 inches) |
| Physical measures and capacities |
|---|
| Dry weight: | 109.0 kg (240.3 pounds) |
| Wheelbase: | 1485 mm (58.5 inches) |
| Fuel capacity: | 5.50 litres (1.45 gallons) |
| Other specifications |
|---|
| Starter: | Kick |
| Further information |
|---|
| Insurance costs | Compare US insurance quotes from the nation's top providers. |
| Finance options | Compare US motorcycle loan quotes from the nation's top providers. |
| Parts finder |
Chaparral provides online schematics & OEM parts for the US. Revzilla offers up to 50% off motorcycle accessories. Ships to most countries.
Also check out our overview of motorcycle webshops at Bikez.info. |
| Ask questions | Join the 07 VOR SM-RC 570 Supermotard discussion group or the general VOR discussion group. |
| Related bikes | List related bikes for comparison of specs. |
|
|
|
Rating sample for this VOR bike
|
Offroad capabilities for the 2007 VOR SM-RC 570 Supermotard:
 (65.9 out of 100)
Click here for complete rating. You can also compare bikes.
|
|
