| VOR's profilation of this bike |
| Off-road VOR’s are strong and powerful, now more reliable and easy to ride thanks to the bike’s design boasting efficient suspensions of öhlins production. |
|
General information |
|
Model name
|
VOR MX 530 Motocross |
|
Model year
|
2007 |
|
Category
|
Cross / motocross |
|
Rating
|
3.1 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
|
Engine and transmission |
|
Displacement
|
444.0 ccm (27.09 cubic inches) |
|
Engine type
|
Single cylinder, four-stroke |
|
Compression
|
12.1:1 |
|
Bore x stroke
|
97.0 x 60.1 mm (3.8 x 2.4 inches) |
|
Valves per cylinder
|
4 |
|
Fuel system
|
Carburettor. Keihin FCR 39 |
|
Fuel control
|
Single Overhead Cams (SOHC) |
|
Ignition
|
Electronic |
|
Cooling system
|
Liquid |
|
Gearbox
|
5-speed |
|
Transmission type
|
Chain (final drive) |
|
Clutch
|
Hidraulic wet multi-plate |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Perimetral frame, CrMo, Oval cross-section spars, aluminium rear frame |
|
Front suspension
|
Aluminium forging with extruded cone shaped arms |
|
Rear suspension
|
Single progressive hydraulic Öhlins shock absorber, stroke 295 mm, low-high speed adjustable preloadm extension and compression |
|
Front tire
|
90/90-21 |
|
Rear tire
|
130/90-19 |
|
Front brakes
|
Single disc |
|
Diameter
|
270 mm (10.6 inches) |
|
Rear brakes
|
Single disc |
|
Diameter
|
220 mm (8.7 inches) |
|
Physical measures and capacities |
|
Dry weight
|
112.0 kg (246.9 pounds) |
|
Overall length
|
2160 mm (85.0 inches) |
|
Ground clearance
|
360 mm (14.2 inches) |
|
Fuel capacity
|
9.00 litres (2.38 US gallons) |
|
Other specifications |
|
Starter
|
Kick |
|
Comments
|
Optional 3-speed gearbox |
