| Viper's profilation of this bike |
| Body work is carbon fiber adding a sexy, lighter and stronger feature. Lighting throughout utilizes LED technology. Fully adjustable lower controls allow riders to customize the bike to their own stature and riding styles. |
|
General information |
|
Model
|
Viper Diamondback |
|
Year model
|
2011 |
|
Type
|
Custom / cruiser |
|
Rating
|
3.6 See the detailed rating of design and look, maintenance cost, engine performance, etc. Compare with any other bike. |
|
Engine and transmission |
|
Engine size
|
2491.0 ccm (152.00 cubic inches) |
|
Type of engine
|
V2, four-stroke |
|
Engine details
|
45 Degree V-Twin |
|
Fuel system
|
Carburettor. Mikuni HSR 45 Flat Slide |
|
Lubrication system
|
Dry sump with oil in the frame technology |
|
Cooling system
|
Air |
|
Gearbox
|
6-speed |
|
Transmission type
|
Belt (final drive) |
|
Clutch
|
Hydraulic High Performance by Rivera |
|
Driveline
|
Rivera Pro 6-Speed with Over-Drive. Primary drive: Hydraulic Chain. Final drive: Patented Viper Rigid Belt Drive. |
|
Exhaust system
|
Tuned 2 into 1 |
|
Chassis, suspension, brakes and wheels |
|
Rake (fork angle)
|
34.0° |
|
Front suspension
|
Inverted Adjustable Cartridge Forks |
|
Rear suspension
|
Viper Chrome Billet Aluminum Swing Arm with Viper Oil Dampened Adjustable Air-Ride |
|
Front tire
|
120/70-21 |
|
Rear tire
|
260/40-18 |
|
Front brakes
|
Single disc |
|
Rear brakes
|
Single disc |
|
Wheels
|
5-spoke chrome |
|
Physical measures and capacities |
|
Dry weight
|
272.2 kg (600.0 pounds) |
|
Seat height
|
610 mm (24.0 inches) If adjustable, lowest setting. |
|
Overall length
|
2540 mm (100.0 inches) |
|
Wheelbase
|
1803 mm (71.0 inches) |
|
Oil capacity
|
4.20 litres (4.44 US quarts) |
|
Other specifications |
|
Color options
|
Custom colors |
|
Starter
|
Electric |
|
Light
|
LED lights |
