Victory Ness Signature Series Jackpot 20062006 Victory Ness Signature Series Jackpot specifications, pictures, reviews and rating |
| Victory's profilation of this bike |
| Compliments of Ness, our new, limited-edition Ness Signature Series Vegas Jackpot models will start you salivating. They should, in fact, come standard with a bib. And why? They’re designed by the reigning kings of custom, Arlen and Cory Ness. |
| General information | |
|---|---|
| Model name | Victory Ness Signature Series Jackpot |
| Model year | 2006 |
| Category | Custom / cruiser |
| Rating | 3.8 See the detailed rating of design and look, maintenance cost, engine performance, etc. Compare with any other bike. |
| Engine and transmission | |
| Displacement | 1638.8 ccm (100.00 cubic inches) |
| Engine type | V2, four-stroke |
| Compression | 9.8:1 |
| Bore x stroke | 101.0 x 102.0 mm (4.0 x 4.0 inches) |
| Valves per cylinder | 4 |
| Fuel system | Injection. Electronic Fuel Injection with 44 mm throttle bodies |
| Fuel control | Single Overhead Cams (SOHC) |
| Cooling system | Air |
| Gearbox | 6-speed |
| Transmission type | Belt (final drive) |
| Clutch | Wet, multi-plate |
| Exhaust system | Staggered slash-cut dual exhaust with common volume |
| Chassis, suspension, brakes and wheels | |
| Rake (fork angle) | 33.5° |
| Front suspension | Conventional telescopic fork, 43 mm diameter, 5.1in/130mm travel |
| Rear suspension | Single, mono-tube gas, forged and cast aluminum with rising rate linkage swing-arm, 3.0in/75mm travel, preload adjustable spring |
| Front tire | 80/90-21 |
| Rear tire | 250/40-B18 |
| Front brakes | Single disc |
| Diameter | 300 mm (11.8 inches) |
| Rear brakes | Single disc |
| Diameter | 300 mm (11.8 inches) |
| Physical measures and capacities | |
| Dry weight | 292.1 kg (644.0 pounds) |
| Seat height | 653 mm (25.7 inches) If adjustable, lowest setting. |
| Overall length | 2446 mm (96.3 inches) |
| Ground clearance | 135 mm (5.3 inches) |
| Wheelbase | 1684 mm (66.3 inches) |
| Fuel capacity | 17.03 litres (4.50 US gallons) |
| Other specifications | |
| Color options | Arlen-Supersonic Blue/Graphic, Cory-Black with Blue Flames |
| Update specs | Report missing specs or required updates. |
| Further information | |
| Insurance costs | Compare US insurance quotes from the nation's top providers. |
| Maintenance | Find parts, fluids. filters, maintenance tools and service manuals at Amazon.com. |
| Ask questions | Join the 06 Victory Ness Signature Series Jackpot discussion group or the general Victory discussion group. |
| Related bikes | List related bikes for comparison of specs. |
| Compare with another motorcycle | |
