| Victory's profilation of this bike |
| With its custom cruiser features like a 250mm rear tire, a color-matched frame, billet wheels, a chrome front end, and a thunderous 106-cubic-inch Freedom® V-Twin engine, the Jackpot® breaks free from the limitations of custom motorcycle design by offering a host of standard upgrades. |
|
General information |
|
Motorcycle name
|
Victory Jackpot |
|
Year model
|
2010 |
|
Type
|
Custom / cruiser |
|
Rating
|
3.5 See the detailed rating of design and look, maintenance cost, engine performance, etc. Compare with any other bike. |
|
Engine and transmission |
|
Engine size
|
1737.1 ccm (106.00 cubic inches) |
|
Type of engine
|
V2, four-stroke |
|
Effect
|
97.0 HP (70.8 kW)) |
|
Compression
|
9.4:1 |
|
Bore x stroke
|
101.0 x 108.0 mm (4.0 x 4.3 inches) |
|
Valves per cylinder
|
4 |
|
Fuel system
|
Injection. Electronic Fuel Injection with dual 45mm throttle body |
|
Fuel control
|
Single Overhead Cams (SOHC) |
|
Cooling system
|
Air |
|
Gearbox
|
6-speed |
|
Transmission type
|
Belt (final drive) |
|
Clutch
|
Wet, multi-plate |
|
Exhaust system
|
Staggered slash-cut dual exhaust with crossover |
|
Chassis, suspension, brakes and wheels |
|
Rake (fork angle)
|
32.9° |
|
Trail
|
125 mm (4.9 inches) |
|
Front suspension
|
Conventional telescopic fork, 43 mm diameter, 5.1 in/130 mm travel |
|
Rear suspension
|
Single, mono-tube gas, cast aluminum with rising-rate linkage, 3.0 in/76 mm travel, preload adjustable spring |
|
Front tire
|
90/90-21 |
|
Rear tire
|
250/40-R18 |
|
Front brakes
|
Single disc |
|
Diameter
|
300 mm (11.8 inches) |
|
Rear brakes
|
Single disc |
|
Diameter
|
300 mm (11.8 inches) |
|
Physical measures and capacities |
|
Dry weight
|
295.7 kg (652.0 pounds) |
|
Power/weight ratio
|
0.3280 HP/kg |
|
Seat height
|
653 mm (25.7 inches) If adjustable, lowest setting. |
|
Overall length
|
2436 mm (95.9 inches) |
|
Ground clearance
|
135 mm (5.3 inches) |
|
Wheelbase
|
1684 mm (66.3 inches) |
|
Fuel capacity
|
17.03 litres (4.50 US gallons) |
|
Oil capacity
|
5.00 litres (5.28 US quarts) |
|
Other specifications |
|
Color options
|
Solid Black, Tequila Gold w/Extreme Graphics |
|
Starter
|
Electric |
