| Victory's profilation of this bike |
| Choose between 17.4 gallons of soft bags storage capacity and 21 gallons of hard bag roominess. Either way your Cross Roads will sport the look of a well-groomed road warrior, and you’ll have plenty of cargo space for another rider’s carry on. |
|
General information |
|
Motorcycle name
|
Victory Cross Roads Delux |
|
Year
|
2012 |
|
Category
|
Touring |
|
Rating
|
Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
|
Engine and transmission |
|
Displacement
|
1737.1 ccm (106.00 cubic inches) |
|
Engine type
|
V2, four-stroke |
|
Engine details
|
50° V-Twin |
|
Power
|
97.0 HP (70.8 kW)) |
|
Torque
|
147.8 Nm (15.1 kgf-m or 109.0 ft.lbs) |
|
Compression
|
9.4:1 |
|
Bore x stroke
|
101.0 x 108.0 mm (4.0 x 4.3 inches) |
|
Valves per cylinder
|
4 |
|
Fuel system
|
Injection |
|
Fuel control
|
Single Overhead Cams (SOHC) |
|
Cooling system
|
Oil & air |
|
Gearbox
|
6-speed |
|
Transmission type
|
Belt (final drive) |
|
Clutch
|
Wet, multi-plate |
|
Exhaust system
|
Split dual exhaust with crossover |
|
Chassis, suspension, brakes and wheels |
|
Rake (fork angle)
|
29.0° |
|
Trail
|
142 mm (5.6 inches) |
|
Front suspension
|
Inverted cartridge telescopic fork, 43 mm diameter |
|
Front wheel travel
|
130 mm (5.1 inches) |
|
Rear suspension
|
Single, mono-tube gas, cast aluminum with constant-rate linkage, air adjustable |
|
Rear wheel travel
|
119 mm (4.7 inches) |
|
Front tire
|
130/70-R18 |
|
Rear tire
|
180/60-R16 |
|
Front brakes
|
Double disc. ABS |
|
Diameter
|
300 mm (11.8 inches) |
|
Rear brakes
|
Single disc. ABS |
|
Diameter
|
300 mm (11.8 inches) |
|
Physical measures and capacities |
|
Dry weight
|
340.0 kg (749.6 pounds) |
|
Power/weight ratio
|
0.2853 HP/kg |
|
Seat height
|
667 mm (26.3 inches) If adjustable, lowest setting. |
|
Overall length
|
2652 mm (104.4 inches) |
|
Ground clearance
|
147 mm (5.8 inches) |
|
Wheelbase
|
1669 mm (65.7 inches) |
|
Fuel capacity
|
21.95 litres (5.80 US gallons) |
|
Oil capacity
|
4.70 litres (4.97 US quarts) |
|
Other specifications |
|
Color options
|
Solid Black, Sunset red, Classic paint
w/Graphics |
|
Starter
|
Electric |
|
Electrical
|
12 volts / 18 amp hours battery. |
