General information |
|
Model
|
Ural Retro 750 |
|
Year
|
2013 |
|
Category
|
Classic |
|
Rating
|
Do you know this bike?
Click here to rate it. We miss 1 vote to show the rating. |
|
Engine and transmission |
|
Displacement
|
749.0 ccm (45.70 cubic inches) |
|
Engine type
|
Two cylinder boxer, four-stroke |
|
Power
|
40.0 HP (29.2 kW)) @ 5600 RPM |
|
Torque
|
51.5 Nm (5.3 kgf-m or 38.0 ft.lbs) @ 4000 RPM |
|
Compression
|
8.6:1 |
|
Bore x stroke
|
78.0 x 78.0 mm (3.1 x 3.1 inches) |
|
Fuel system
|
Carburettor. Dual Keihin L 22 AA, 32mm |
|
Fuel control
|
Overhead Valves (OHV) |
|
Ignition
|
Full electronic C.D.I. |
|
Cooling system
|
Air |
|
Gearbox
|
4-speed |
|
Transmission type
|
Shaft drive (cardan) (final drive) |
|
Clutch
|
Dry, dual disk |
|
Driveline
|
4 speed with reverse and shaft drive |
|
Fuel consumption
|
7.84 litres/100 km (12.8 km/l or 30.00 mpg) |
|
Greenhouse gases
|
181.9 CO2 g/km. (CO2 - Carbon dioxide emission) |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Double loop steel tube |
|
Front suspension
|
Marzhocchi Telescopic Forks |
|
Rear suspension
|
Sachs Hydraulic shock absorbers |
|
Front tire
|
3.50-18 |
|
Rear tire
|
3.50-18 |
|
Front brakes
|
Single disc. Bremo |
|
Rear brakes
|
Expanding brake (drum brake). Mechanically actuated drumbrakes at rear and sidecar wheel. |
|
Wheels
|
Aluminum, steel spokes, cast alum. hubs. Front, rear, and sidecar 18in. |
|
Physical measures and capacities |
|
Dry weight
|
325.0 kg (716.5 pounds) |
|
Power/weight ratio
|
0.1231 HP/kg |
|
Seat height
|
750 mm (29.5 inches) If adjustable, lowest setting. |
|
Overall height
|
1020 mm (40.2 inches) |
|
Overall length
|
2224 mm (87.6 inches) |
|
Overall width
|
1630 mm (64.2 inches) |
|
Ground clearance
|
140 mm (5.5 inches) |
|
Fuel capacity
|
22.00 litres (5.81 US gallons) |
|
Other specifications |
|
Color options
|
Black with pinstripes |
|
Starter
|
Electric & kick |
|
Electrical
|
14 Volt DC w/22 Amp 770 Watt Alternator |
|
Carrying capacity
|
2.9 cubic ft. trunck volume |
|
Comments
|
Windscreen. Made by Irbit Motorcycle Works (IMZ), Irbit, 250 km east of the Ural mountains in Siberia, Russia. |
