General information |
|
Model name
|
UM Xtreet 125 |
|
Year of manufacture
|
2010 |
|
Type
|
Sport |
|
Rating
|
Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
|
Engine and transmission |
|
Engine size
|
125.0 ccm (7.63 cubic inches) |
|
Type of engine
|
Single cylinder, four-stroke |
|
Compression
|
9.0:1 |
|
Bore x stroke
|
56.0 x 49.5 mm (2.2 x 1.9 inches) |
|
Fuel system
|
Carburettor |
|
Fuel control
|
Single Overhead Cams (SOHC) |
|
Ignition
|
CDI |
|
Cooling system
|
Air |
|
Gearbox
|
5-speed |
|
Transmission type
|
Chain (final drive) |
|
Chassis, suspension, brakes and wheels |
|
Front suspension
|
105mm Sleeve Style Telescopic Fork |
|
Rear suspension
|
Monoshock - Swingarm with single adjustable shock absorber |
|
Front tire
|
110/70-17 |
|
Rear tire
|
130/70-17 |
|
Front brakes
|
Single disc |
|
Rear brakes
|
Single disc |
|
Physical measures and capacities |
|
Dry weight
|
122.0 kg (269.0 pounds) |
|
Seat height
|
870 mm (34.3 inches) If adjustable, lowest setting. |
|
Overall height
|
1000 mm (39.4 inches) |
|
Overall length
|
2000 mm (78.7 inches) |
|
Overall width
|
730 mm (28.7 inches) |
|
Wheelbase
|
1350 mm (53.1 inches) |
|
Fuel capacity
|
15.50 litres (4.10 US gallons) |
|
Other specifications |
|
Color options
|
Black, Blue, Red |
|
Starter
|
Electric & kick |
