| UM's profilation of this bike |
| Incredible performance and features for off-road mid-sized. |
|
General information |
|
Model name
|
UM DTF-150 |
|
Model year
|
2007 |
|
Category
|
Enduro / offroad |
| Price as new | US$ 1899. MSRP depends on country, taxes, accessories, etc. |
|
Rating
|
Do you know this bike?
Click here to rate it. We miss 1 vote to show the rating. |
|
Engine and transmission |
|
Displacement
|
149.0 ccm (9.09 cubic inches) |
|
Engine type
|
Single cylinder, four-stroke |
|
Compression
|
9.2:1 |
|
Bore x stroke
|
62.0 x 49.5 mm (2.4 x 1.9 inches) |
|
Cooling system
|
Air |
|
Gearbox
|
5-speed |
|
Transmission type
|
Chain (final drive) |
|
Clutch
|
Manual clutch |
|
Chassis, suspension, brakes and wheels |
|
Front suspension
|
Telescopic fork |
|
Rear suspension
|
Swing arm with single shock |
|
Front tire
|
70/100-19 |
|
Rear tire
|
90/100-16 |
|
Front brakes
|
Single disc |
|
Diameter
|
241 mm (9.5 inches) |
|
Rear brakes
|
Single disc |
|
Diameter
|
190 mm (7.5 inches) |
|
Physical measures and capacities |
|
Dry weight
|
77.6 kg (171.0 pounds) |
|
Seat height
|
787 mm (31.0 inches) If adjustable, lowest setting. |
|
Overall length
|
1880 mm (74.0 inches) |
|
Overall width
|
864 mm (34.0 inches) |
|
Wheelbase
|
1168 mm (46.0 inches) |
|
Fuel capacity
|
5.60 litres (1.48 US gallons) |
|
Reserve fuel capacity
|
1.09 litres (0.29 US gallons) |
|
Other specifications |
|
Color options
|
Blue, Red |
|
Starter
|
Electric & kick |
|
Comments
|
UM is an abbreviation of United Motors. |
