| UM's profilation of this bike |
| The DSF 200 has a sturdy diamond frame, ultra light aluminum wheels and handlebars, wave rotor disk brakes, brush guards and compact luggage rack, and all the other features it takes to get you to wherever your adventurous spirit wants to go. |
|
General information |
|
Motorcycle name
|
UM DSF-200 |
|
Year of manufacture
|
2007 |
|
Type
|
Enduro / offroad |
| Price as new | US$ 2799. MSRP depends on country, taxes, accessories, etc. |
|
Rating
|
3.3 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
|
Engine and transmission |
|
Engine size
|
196.0 ccm (11.96 cubic inches) |
|
Type of engine
|
Single cylinder, four-stroke |
|
Compression
|
9.2:1 |
|
Bore x stroke
|
69.0 x 53.0 mm (2.7 x 2.1 inches) |
|
Fuel system
|
Carburettor |
|
Ignition
|
CDI |
|
Cooling system
|
Oil & air |
|
Gearbox
|
5-speed |
|
Transmission type
|
Chain (final drive) |
|
Clutch
|
Manual |
|
Chassis, suspension, brakes and wheels |
|
Front suspension
|
Telescopic fork |
|
Rear suspension
|
Single shock |
|
Front tire
|
3.0-21 |
|
Rear tire
|
4.1-18 |
|
Front brakes
|
Single disc |
|
Diameter
|
292 mm (11.5 inches) |
|
Rear brakes
|
Single disc |
|
Diameter
|
267 mm (10.5 inches) |
|
Physical measures and capacities |
|
Dry weight
|
122.9 kg (271.0 pounds) |
|
Seat height
|
889 mm (35.0 inches) If adjustable, lowest setting. |
|
Overall height
|
1168 mm (46.0 inches) |
|
Overall length
|
2184 mm (86.0 inches) |
|
Overall width
|
991 mm (39.0 inches) |
|
Wheelbase
|
1422 mm (56.0 inches) |
|
Other specifications |
|
Starter
|
Electric & kick |
|
Comments
|
UM is an abbreviation of United Motors. |
