TVS Apache RTR 160 Hyper Edge 20122012 TVS Apache RTR 160 Hyper Edge specifications, pictures, reviews and rating |
| General information | |
|---|---|
| Model name | TVS Apache RTR 160 Hyper Edge |
| Model year | 2012 |
| Category | Sport |
| Rating | 3.9 Check out the detailed rating of racing track capabilities, engine performance, accident risk, etc. Compare with any other bike. |
| Engine and transmission | |
| Displacement | 159.7 ccm (9.74 cubic inches) |
| Engine type | Single cylinder, four-stroke |
| Power output | 15.0 HP (11.0 kW)) @ 8500 RPM |
| Torque | 13.1 Nm (1.3 kgf-m or 9.7 ft.lbs) @ 6000 RPM |
| Compression | 9.5:1 |
| Bore x stroke | 62.0 x 52.9 mm (2.4 x 2.1 inches) |
| Valves per cylinder | 2 |
| Fuel system | Carburettor. Mikuni BS-26 |
| Fuel control | Single Overhead Cams (SOHC) |
| Ignition | IDI-Dual mode digital ignition |
| Gearbox | 5-speed |
| Transmission type | Chain (final drive) |
| Clutch | Wet, Multi-Plate |
| Chassis, suspension, brakes and wheels | |
| Frame type | Double cradle |
| Front suspension | Telescopic fork |
| Front wheel travel | 105 mm (4.1 inches) |
| Rear suspension | Monotube inverted gas filled shochs with spring aid |
| Front tire | 90/90-17 |
| Rear tire | 100/80-18 |
| Front brakes | Single disc. Petal disk |
| Diameter | 270 mm (10.6 inches) |
| Rear brakes | Expanding brake (drum brake) |
| Diameter | 130 mm (5.1 inches) |
| Wheels | Six spoke black rims |
| Physical measures and capacities | |
| Weight incl. oil, gas, etc | 136.0 kg (299.8 pounds) |
| Seat height | 790 mm (31.1 inches) If adjustable, lowest setting. |
| Overall height | 1050 mm (41.3 inches) |
| Overall length | 2020 mm (79.5 inches) |
| Overall width | 730 mm (28.7 inches) |
| Ground clearance | 180 mm (7.1 inches) |
| Wheelbase | 1300 mm (51.2 inches) |
| Fuel capacity | 16.00 litres (4.23 US gallons) |
| Reserve fuel capacity | 2.50 litres (0.66 US gallons) |
| Other specifications | |
| Color options | Black |
| Starter | Electric & kick |
| Comments | Made in India. |
