General information |
Model name
|
TVS Apache RTR 160 Hyper Edge |
Model year
|
2012 |
Category
|
Sport |
Rating
|
3.9 Check out the detailed rating of racing track capabilities, engine performance, accident risk, etc. Compare with any other bike. |
Engine and transmission |
Displacement
|
159.7 ccm (9.74 cubic inches) |
Engine type
|
Single cylinder, four-stroke |
Power output
|
15.0 HP (11.0 kW)) @ 8500 RPM |
Torque
|
13.1 Nm (1.3 kgf-m or 9.7 ft.lbs) @ 6000 RPM |
Compression
|
9.5:1 |
Bore x stroke
|
62.0 x 52.9 mm (2.4 x 2.1 inches) |
Valves per cylinder
|
2 |
Fuel system
|
Carburettor. Mikuni BS-26 |
Fuel control
|
Single Overhead Cams (SOHC) |
Ignition
|
IDI-Dual mode digital ignition |
Gearbox
|
5-speed |
Transmission type
|
Chain (final drive) |
Clutch
|
Wet, Multi-Plate |
Chassis, suspension, brakes and wheels |
Frame type
|
Double cradle |
Front suspension
|
Telescopic fork |
Front wheel travel
|
105 mm (4.1 inches) |
Rear suspension
|
Monotube inverted gas filled shochs with spring aid |
Front tire
|
90/90-17 |
Rear tire
|
100/80-18 |
Front brakes
|
Single disc. Petal disk |
Diameter
|
270 mm (10.6 inches) |
Rear brakes
|
Expanding brake (drum brake) |
Diameter
|
130 mm (5.1 inches) |
Wheels
|
Six spoke black rims |
Physical measures and capacities |
Weight incl. oil, gas, etc
|
136.0 kg (299.8 pounds) |
Seat height
|
790 mm (31.1 inches) If adjustable, lowest setting. |
Overall height
|
1050 mm (41.3 inches) |
Overall length
|
2020 mm (79.5 inches) |
Overall width
|
730 mm (28.7 inches) |
Ground clearance
|
180 mm (7.1 inches) |
Wheelbase
|
1300 mm (51.2 inches) |
Fuel capacity
|
16.00 litres (4.23 US gallons) |
Reserve fuel capacity
|
2.50 litres (0.66 US gallons) |
Other specifications |
Color options
|
Black |
Starter
|
Electric & kick |
Comments
|
Made in India. |
