TVS Apache 150 20092009 TVS Apache 150 specifications, pictures, reviews and rating |
 2009 TVS Apache 150. Picture credits - TVS. Submit more pictures. |
|
| General information | |
|---|---|
| Model: | TVS Apache 150 |
| Year: | 2009 |
| Category: | Sport |
| Rating: | 3.3 Check out the detailed rating of racing track capabilities, engine performance, accident risk, etc. Compare with any other bike. |
| Engine and transmission | |
| Displacement: | 147.4 ccm (8.99 cubic inches) |
| Engine type: | Single cylinder, four-stroke |
| Power: | 9.9 HP (7.2 kW)) @ 8500 RPM |
| Torque: | 12.3 Nm (1.3 kgf-m or 9.1 ft.lbs) @ 6500 RPM |
| Compression: | 9.5:1 |
| Bore x stroke: | 57.0 x 57.8 mm (2.2 x 2.3 inches) |
| Fuel system: | Carburettor |
| Fuel control: | Single Overhead Cams (SOHC) |
| Ignition: | IDI-Dual mode digital ignition |
| Gearbox: | 5-speed |
| Clutch: | Wet, multiplate |
| Chassis, suspension, brakes and wheels | |
| Frame type: | Double cradle |
| Front suspension: | Telescopic fork |
| Front wheel travel: | 105 mm (4.1 inches) |
| Rear suspension: | Monotube inverted Gas filled Shox (MIG) |
| Front tyre: | 90/90-17 |
| Rear tyre: | 100/80-18 |
| Front brakes: | Single disc |
| Diameter: | 270 mm (10.6 inches) |
| Rear brakes: | Expanding brake (drum brake) |
| Diameter: | 130 mm (5.1 inches) |
| Physical measures and capacities | |
| Weight incl. oil, gas, etc: | 136.0 kg (299.8 pounds) |
| Wheelbase: | 1260 mm (49.6 inches) |
| Fuel capacity: | 16.00 litres (4.23 gallons) |
| Reserve fuel capacity: | 2.50 litres (0.66 gallons) |
| Other specifications | |
| Starter: | Electric & kick |
| Comments: | TVS is made in India in cooperation with Suzuki. |
