| Triumph's profilation of this bike |
| A global hit since its introduction in 2007, the Street Triple fuses the style and attitude of the iconic Speed Triple with the performance and agility of the class leading Daytona 675 supersports machine.
The result is a truly impressive middleweight streetfighter that has attained critical success around the world. |
|
General information |
|
Motorcycle name
|
Triumph Street Triple |
|
Year model
|
2010 |
|
Type
|
Naked bike |
|
Rating
|
3.8 See the detailed rating of engine performance, design and look, accident risk, etc. Compare with any other motorcycle. |
|
Engine and transmission |
|
Engine size
|
675.0 ccm (41.19 cubic inches) |
|
Type of engine
|
In-line three, four-stroke |
|
Effect
|
105.9 HP (77.3 kW)) @ 11700 RPM |
|
Torque
|
69.0 Nm (7.0 kgf-m or 50.9 ft.lbs) @ 9100 RPM |
|
Compression
|
12.0:1 |
|
Bore x stroke
|
74.0 x 52.3 mm (2.9 x 2.1 inches) |
|
Valves per cylinder
|
4 |
|
Fuel system
|
Injection. Multipoint sequential electronic fuel injection with SAI |
|
Fuel control
|
Double Overhead Cams/Twin Cam (DOHC) |
|
Cooling system
|
Liquid |
|
Gearbox
|
6-speed |
|
Transmission type
|
Chain (final drive) |
|
Clutch
|
Wet. multi-plate |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Aluminium beam twin spar |
|
Rake (fork angle)
|
24.3° |
|
Trail
|
95 mm (3.8 inches) |
|
Front suspension
|
Kayaba 41mm upside down forks |
|
Front wheel travel
|
120 mm (4.7 inches) |
|
Rear suspension
|
Kayaba monoshock with adjustable preload |
|
Rear wheel travel
|
126 mm (5.0 inches) |
|
Front tire
|
120/70-ZR17 |
|
Rear tire
|
180/55-ZR17 |
|
Front brakes
|
Double disc. Nissin 2-piston sliding calipers |
|
Diameter
|
308 mm (12.1 inches) |
|
Rear brakes
|
Single disc. Nissin single piston caliper |
|
Diameter
|
220 mm (8.7 inches) |
|
Physical measures and capacities |
|
Dry weight
|
167.0 kg (368.2 pounds) |
|
Weight incl. oil, gas, etc
|
189.0 kg (416.7 pounds) |
|
Power/weight ratio
|
0.6344 HP/kg |
|
Seat height
|
800 mm (31.5 inches) If adjustable, lowest setting. |
|
Overall height
|
1060 mm (41.7 inches) |
|
Overall length
|
2000 mm (78.7 inches) |
|
Overall width
|
735 mm (28.9 inches) |
|
Wheelbase
|
1395 mm (54.9 inches) |
|
Fuel capacity
|
17.40 litres (4.60 US gallons) |
|
Other specifications |
|
Color options
|
Jet Black, Fusion White, Tornado Red |
|
Starter
|
Electric |
