| Triumph's profilation of this bike |
| The new Sprint ST has been given a number of improvements to ensure it remains one of the world’s favourite sports-tourers. Updates include new reflector-style triple headlight unit; re-designed cockpit; the same stunning 1050cc inline triple engine, but with latest spec ECU for ultra-smooth throttle response. |
|
General information |
|
Model name
|
Triumph Sprint ST |
|
Year
|
2011 |
|
Category
|
Sport touring |
|
Rating
|
3.4 See the detailed rating of touring capabilities, reliability, accident risk, etc. Compare with any other motorbike. |
|
Engine and transmission |
|
Displacement
|
1050.0 ccm (64.07 cubic inches) |
|
Engine type
|
In-line three, four-stroke |
|
Power
|
128.7 HP (94.0 kW)) @ 9250 RPM |
|
Torque
|
108.0 Nm (11.0 kgf-m or 79.7 ft.lbs) @ 6300 RPM |
|
Bore x stroke
|
79.0 x 71.4 mm (3.1 x 2.8 inches) |
|
Valves per cylinder
|
4 |
|
Fuel system
|
Injection. Multipoint sequential electronic injection |
|
Fuel control
|
Double Overhead Cams/Twin Cam (DOHC) |
|
Cooling system
|
Liquid |
|
Gearbox
|
6-speed |
|
Transmission type
|
Chain (final drive) |
|
Clutch
|
Wet. multi-plate |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Aluminium beam perimeter. Single-sided, aluminium alloy swing arm with eccentric chain adjuster |
|
Rake (fork angle)
|
24.0° |
|
Front suspension
|
Showa 43mm cartridge forks with dual rate springs and adjustable preload 127mm travel |
|
Rear suspension
|
Showa Monoshock with adjustable preload and rebound damping. 119mm travel |
|
Front tire
|
120/70-ZR17 |
|
Rear tire
|
180/55-ZR17 |
|
Front brakes
|
Double disc. ABS |
|
Diameter
|
320 mm (12.6 inches) |
|
Rear brakes
|
Single disc. ABS |
|
Diameter
|
255 mm (10.0 inches) |
|
Wheels
|
Cast aluminium alloy 5-spoke |
|
Physical measures and capacities |
|
Dry weight
|
210.0 kg (463.0 pounds) |
|
Power/weight ratio
|
0.6130 HP/kg |
|
Seat height
|
805 mm (31.7 inches) If adjustable, lowest setting. |
|
Overall height
|
1215 mm (47.8 inches) |
|
Overall length
|
2114 mm (83.2 inches) |
|
Wheelbase
|
1457 mm (57.4 inches) |
|
Fuel capacity
|
20.00 litres (5.28 US gallons) |
|
Oil capacity
|
3.50 litres (3.7 US quarts) |
|
Other specifications |
|
Color options
|
Phantom black, Tornado red |
|
Starter
|
Electric |
|
Instruments
|
Analogue speedometer, trip computer and analogue tachometer |
| Update specs | Report missing specs or required updates. |
|
Further information |
| Insurance costs | Compare US insurance quotes from the nation's top providers. |
| Parts finder |
Check out our overview of motorcycle webshops at Bikez.info. |
| Maintenance | Find parts, fluids. filters, maintenance tools and service manuals at Amazon.com. |
| Ask questions | Join the 11 Triumph Sprint ST discussion group or the general Triumph discussion group. |
| Related bikes | List related bikes for comparison of specs. |
|
|
|
Rating sample for this Triumph bike
|
Reliability for the 2011 Triumph Sprint ST:
 (69.9 out of 100)
Click here for complete rating. You can also compare bikes.
|
|
