Triumph Speedmaster 20102010 Triumph Speedmaster specifications, pictures, reviews and rating |
| Triumph's profilation of this bike |
| Stripped down. Mean. Moody. The Speedmaster is a tough looking, no-nonsense sports cruiser that’s dripping with attitude. |
| General information | |
|---|---|
| Model | Triumph Speedmaster |
| Year | 2010 |
| Category | Custom / cruiser |
| Rating | 3.7 See the detailed rating of design and look, maintenance cost, engine performance, etc. Compare with any other bike. |
| Engine and transmission | |
| Displacement | 865.0 ccm (52.78 cubic inches) |
| Engine type | Twin, four-stroke |
| Power | 61.7 HP (45.0 kW)) @ 6800 RPM |
| Torque | 74.0 Nm (7.5 kgf-m or 54.6 ft.lbs) @ 3300 RPM |
| Compression | 9.2:1 |
| Bore x stroke | 90.0 x 68.0 mm (3.5 x 2.7 inches) |
| Fuel system | Injection. Multipoint sequential electonic fuel injection with SAI |
| Fuel control | Double Overhead Cams/Twin Cam (DOHC) |
| Cooling system | Air |
| Gearbox | 5-speed |
| Transmission type | Chain (final drive) |
| Clutch | Wet. multi-plate |
| Chassis, suspension, brakes and wheels | |
| Frame type | Tubular steel cradle. Twin-sided, tubular steel swingarm. |
| Rake (fork angle) | 33.3° |
| Trail | 153 mm (6.0 inches) |
| Front suspension | Kayaba 41mm forks with polished stainless steel shrouds and polished lowers |
| Front wheel travel | 130 mm (5.1 inches) |
| Rear suspension | Kayaba chromed spring twin shocks with adjustable preload |
| Rear wheel travel | 96 mm (3.8 inches) |
| Front tire | 110/80-R18 |
| Rear tire | 170/80-B15 |
| Front brakes | Double disc |
| Diameter | 310 mm (12.2 inches) |
| Rear brakes | Single disc |
| Diameter | 285 mm (11.2 inches) |
| Physical measures and capacities | |
| Dry weight | 229.0 kg (504.9 pounds) |
| Weight incl. oil, gas, etc | 250.0 kg (551.2 pounds) |
| Power/weight ratio | 0.2693 HP/kg |
| Seat height | 720 mm (28.3 inches) If adjustable, lowest setting. |
| Overall height | 1160 mm (45.7 inches) |
| Overall length | 2420 mm (95.3 inches) |
| Overall width | 830 mm (32.7 inches) |
| Wheelbase | 1655 mm (65.2 inches) |
| Fuel capacity | 19.30 litres (5.10 US gallons) |
| Other specifications | |
| Color options | Phantom Black, Phantom Black/New England White |
| Starter | Electric |
| Update specs | Report missing specs or required updates. |
| Further information | |
| Insurance costs | Compare US insurance quotes from the nation's top providers. |
| Parts finder | Check out our overview of motorcycle webshops at Bikez.info. |
| Maintenance | Find parts, fluids. filters, maintenance tools and service manuals at Amazon.com. |
| Ask questions | Join the 10 Triumph Speedmaster discussion group or the general Triumph discussion group. |
| Related bikes | List related bikes for comparison of specs. |
| Compare with another motorcycle | |
Buying a bike starts at Bikez
Get a list of related motorbikes before you buy this Triumph. Inspect technical data. Look at photos. Read the riders' comments at the bike's discussion group. And check out the bike's reliability, repair costs, etc. Show any 2010 Triumph Speedmaster for sale on our Bikez.biz Motorcycle Classifieds. You can also sign up for e-mail notification when such bikes are advertised in the future. And advertise your old MC for sale. Our efficient ads are free. You are also welcome to read and submit motorcycle reviews.| Rating sample for this Triumph bike | |
Reliability for the 2010 Triumph Speedmaster:  (85.5 out of 100)Click here for complete rating. |
|
