| Triumph's profilation of this bike |
| Pulled back bars, footboards, large dual seat combined with classic styled reverse cone silencers and a two tone paint scheme could give the impression that it’s a little less purposeful than the standard Rocket III.
|
|
General information |
|
Model name
|
Triumph Rocket III Classic |
|
Model year
|
2009 |
|
Category
|
Classic |
|
Rating
|
2.8 See the detailed rating of design and look, engine performance, reliability, fun-factor, etc. Compare with any other bike. |
|
Engine and transmission |
|
Displacement
|
2294.0 ccm (139.98 cubic inches) |
|
Engine type
|
In-line three, four-stroke |
|
Compression
|
8.7:1 |
|
Bore x stroke
|
101.6 x 94.3 mm (4.0 x 3.7 inches) |
|
Fuel system
|
Injection. Multipoint sequential electonic fuel injection twin butterflies. progressive linkage on primary butterflies |
|
Fuel control
|
Double Overhead Cams/Twin Cam (DOHC) |
|
Cooling system
|
Liquid |
|
Gearbox
|
5-speed |
|
Transmission type
|
Shaft drive (cardan) (final drive) |
|
Clutch
|
Wet. multi-plate |
|
Chassis, suspension, brakes and wheels |
|
Rake (fork angle)
|
32.0° |
|
Trail
|
152 mm (6.0 inches) |
|
Front suspension
|
Kayaba 43mm upside down forks. 120mm travel |
|
Rear suspension
|
Kayaba chromed spring twin shocks with 5 position adjustable preload. 105mm wheel travel |
|
Front tire
|
150/80-R17 |
|
Rear tire
|
240/50-R16 |
|
Front brakes
|
Double disc |
|
Diameter
|
320 mm (12.6 inches) |
|
Rear brakes
|
Single disc |
|
Diameter
|
316 mm (12.4 inches) |
|
Physical measures and capacities |
|
Dry weight
|
320.0 kg (705.5 pounds) |
|
Seat height
|
740 mm (29.1 inches) If adjustable, lowest setting. |
|
Overall height
|
1165 mm (45.9 inches) |
|
Overall length
|
2500 mm (98.4 inches) |
|
Overall width
|
970 mm (38.2 inches) |
|
Wheelbase
|
1695 mm (66.7 inches) |
|
Fuel capacity
|
24.00 litres (6.34 US gallons) |
|
Other specifications |
|
Color options
|
Pacific Blue/Aluminium Silver, Cherry Red/New England White |
