| Triumph's profilation of this bike |
| A modern day roadster with a tangible connection to the classic style of times gone by, the Bonneville mixes timeless British engineering with modern technology and thinking. The result is captivating. |
|
General information |
|
Motorcycle name
|
Triumph Bonneville |
|
Model year
|
2005 |
|
Category
|
Classic |
|
Rating
|
3.6 See the detailed rating of design and look, engine performance, reliability, fun-factor, etc. Compare with any other bike. |
|
Engine and transmission |
|
Displacement
|
790.0 ccm (48.21 cubic inches) |
|
Engine type
|
Twin, four-stroke |
|
Power output
|
62.0 HP (45.3 kW)) @ 7400 RPM |
|
Torque
|
62.0 Nm (6.3 kgf-m or 45.7 ft.lbs) @ 3500 RPM |
|
Compression
|
9.2:1 |
|
Bore x stroke
|
86.0 x 68.0 mm (3.4 x 2.7 inches) |
|
Fuel system
|
Carburettor. Twin carburettors with throttle position sensor and electric carburettor heaters |
|
Fuel control
|
Double Overhead Cams/Twin Cam (DOHC) |
|
Ignition
|
Digital - inductive type |
|
Cooling system
|
Air |
|
Gearbox
|
5-speed |
|
Transmission type
|
Chain (final drive) |
|
Clutch
|
Wet, multi-plate |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Tubular steel cradle |
|
Rake (fork angle)
|
28.0° |
|
Front suspension
|
41mm forks |
|
Rear suspension
|
Chromed spring twin shocks with adjustable preload |
|
Front tire
|
100/90-19 |
|
Rear tire
|
130/80-17 |
|
Front brakes
|
Single disc. 2-piston calipers |
|
Diameter
|
310 mm (12.2 inches) |
|
Rear brakes
|
Single disc. 2-piston calipers |
|
Diameter
|
255 mm (10.0 inches) |
|
Physical measures and capacities |
|
Dry weight
|
205.0 kg (451.9 pounds) |
|
Power/weight ratio
|
0.3024 HP/kg |
|
Seat height
|
775 mm (30.5 inches) If adjustable, lowest setting. |
|
Overall height
|
1100 mm (43.3 inches) |
|
Overall length
|
2230 mm (87.8 inches) |
|
Overall width
|
840 mm (33.1 inches) |
|
Wheelbase
|
1500 mm (59.1 inches) |
|
Other specifications |
|
Color options
|
Jet Black, Goodwood Green, Aegean Blue (Jet Black also available with black engine finish) |
