| General information |
|---|
| Model | Triumph America |
| Year | 2012 |
| Category | Custom / cruiser |
| Price as new | US$ 8299. MSRP depends on country, taxes, accessories, etc. |
| Rating | 3.9 See the detailed rating of design and look, maintenance cost, engine performance, etc. Compare with any other bike. |
| Engine and transmission |
|---|
| Displacement | 865.0 ccm (52.78 cubic inches) |
| Engine type | Twin, four-stroke |
| Engine details | 270 degree firing interval |
| Power | 61.0 HP (44.5 kW)) @ 6800 RPM |
| Torque | 72.0 Nm (7.3 kgf-m or 53.1 ft.lbs) @ 3300 RPM |
| Compression | 9.2:1 |
| Bore x stroke | 90.0 x 68.0 mm (3.5 x 2.7 inches) |
| Fuel system | Injection. Multipoint sequential electronic fuel injection with SAI |
| Fuel control | Double Overhead Cams/Twin Cam (DOHC) |
| Ignition | Digital-inductive type via engine management system |
| Cooling system | Air |
| Gearbox | 5-speed |
| Transmission type | Chain (final drive) |
| Clutch | Wet. multi-plate |
| Driveline | X ring chain |
| Exhaust system | Stainless steel twin-walled headers. twin chromed silencers |
| Chassis, suspension, brakes and wheels |
|---|
| Frame type | Tubular steel cradle |
| Rake (fork angle) | 33.0° |
| Front suspension | Kayaba 41mm forks with polished stainless steel shrouds and polished lowers. 120mm travel |
| Rear suspension | Kayaba chromed spring twin shocks with adjustable preload. 96mm rear wheel travel |
| Front tire | 130/90-R16 |
| Rear tire | 170/80-B15 |
| Front brakes | Single disc. Nissin 2-piston floating caliper |
| Diameter | 310 mm (12.2 inches) |
| Rear brakes | Single disc. Nissin 2-piston floating caliper |
| Diameter | 285 mm (11.2 inches) |
| Wheels | Cast aluminium alloy 12-spoke |
| Physical measures and capacities |
|---|
| Weight incl. oil, gas, etc | 250.0 kg (551.2 pounds) |
| Seat height | 690 mm (27.2 inches) If adjustable, lowest setting. |
| Overall height | 1141 mm (44.9 inches) |
| Overall length | 2420 mm (95.3 inches) |
| Overall width | 821 mm (32.3 inches) |
| Wheelbase | 1617 mm (63.7 inches) |
| Fuel capacity | 19.30 litres (5.10 US gallons) |
| Oil capacity | 4.50 litres (4.76 US quarts) |
| Other specifications |
|---|
| Color options | Phantom Black. Eclipse Blue/Crystal White |
| Starter | Electric |
| Instruments | Analogue speedometer with odometer and trip information. |
