| Triumph's profilation of this bike |
| Shrouded front forks with polished lowers, chromed single headlamp and chromed engine covers, machined cast wheels, chromed detailing and twin reverse cone pipes are all evidence of the attention to detail that makes sure the America stands out wherever it goes.
|
|
General information |
|
Motorcycle name
|
Triumph America |
|
Year
|
2009 |
|
Category
|
Custom / cruiser |
|
Rating
|
3.5 See the detailed rating of design and look, maintenance cost, engine performance, etc. Compare with any other bike. |
|
Engine and transmission |
|
Displacement
|
865.0 ccm (52.78 cubic inches) |
|
Engine type
|
Twin, four-stroke |
|
Power
|
61.7 HP (45.0 kW)) @ 6800 RPM |
|
Torque
|
74.0 Nm (7.5 kgf-m or 54.6 ft.lbs) @ 3300 RPM |
|
Compression
|
9.2:1 |
|
Bore x stroke
|
90.0 x 68.0 mm (3.5 x 2.7 inches) |
|
Fuel system
|
Injection. Multipoint sequential electronic fuel injection |
|
Fuel control
|
Double Overhead Cams/Twin Cam (DOHC) |
|
Ignition
|
--) |
|
Cooling system
|
Air |
|
Gearbox
|
5-speed |
|
Clutch
|
Wet. multi-plate |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Tubular steel cradle |
|
Rake (fork angle)
|
33.3° |
|
Trail
|
153 mm (6.0 inches) |
|
Front suspension
|
41mm forks 130mm travel |
|
Rear suspension
|
Chromed spring twin shocks with adjustable preload. 96mm rear wheel travel |
|
Front tire
|
110/90-18 |
|
Rear tire
|
170/80-15 |
|
Front brakes
|
Single disc |
|
Diameter
|
310 mm (12.2 inches) |
|
Rear brakes
|
Single disc |
|
Diameter
|
285 mm (11.2 inches) |
|
Physical measures and capacities |
|
Dry weight
|
226.0 kg (498.2 pounds) |
|
Power/weight ratio
|
0.2729 HP/kg |
|
Seat height
|
720 mm (28.3 inches) If adjustable, lowest setting. |
|
Overall height
|
1170 mm (46.1 inches) |
|
Overall length
|
2420 mm (95.3 inches) |
|
Overall width
|
960 mm (37.8 inches) |
|
Wheelbase
|
1655 mm (65.2 inches) |
|
Fuel capacity
|
19.30 litres (5.10 US gallons) |
|
Other specifications |
|
Color options
|
Pacific Blue/Aegean Blue. Pacific Blue/New England White. Phantom Black |
|
Starter
|
Electric |
