| General information |
|---|
| Model | Triumph America |
| Year | 2005 |
| Category | Custom / cruiser |
| Rating | 3.6 See the detailed rating of design and look, maintenance cost, engine performance, etc. Compare with any other bike. |
| Engine and transmission |
|---|
| Displacement | 790.0 ccm (48.21 cubic inches) |
| Engine type | Twin, four-stroke |
| Power | 62.0 HP (45.3 kW)) @ 7400 RPM |
| Torque | 60.0 Nm (6.1 kgf-m or 44.3 ft.lbs) @ 3500 RPM |
| Compression | 9.2:1 |
| Bore x stroke | 86.0 x 68.0 mm (3.4 x 2.7 inches) |
| Fuel system | Carburettor. Twin carburettors with throttle position sensor and electric carburettor heaters |
| Fuel control | Double Overhead Cams/Twin Cam (DOHC) |
| Ignition | Digital - inductive type |
| Cooling system | Air |
| Gearbox | 5-speed |
| Transmission type | Chain (final drive) |
| Clutch | Wet, multi-plate |
| Chassis, suspension, brakes and wheels |
|---|
| Frame type | Tubular steel cradle |
| Rake (fork angle) | 33.3° |
| Front suspension | 41mm forks |
| Rear suspension | Chromed spring twin rear shocks with adjustable preload |
| Front brakes | Single disc |
| Diameter | 310 mm (12.2 inches) |
| Rear brakes | Single disc |
| Diameter | 285 mm (11.2 inches) |
| Physical measures and capacities |
|---|
| Dry weight | 226.0 kg (498.2 pounds) |
| Power/weight ratio | 0.2743 HP/kg |
| Seat height | 720 mm (28.3 inches) If adjustable, lowest setting. |
| Overall height | 1170 mm (46.1 inches) |
| Overall length | 2420 mm (95.3 inches) |
| Overall width | 960 mm (37.8 inches) |
| Wheelbase | 1655 mm (65.2 inches) |
| Other specifications |
|---|
| Color options | Jet Black, Goodwood Green/Silver, Mulberry Red/Graphite |
