| Tomberlin's profilation of this bike |
| The SDX-200 is a Transitional ATV. It is the perfect way to bridge the gap between a youth and adult rider. |
|
General information |
|
Motorcycle name
|
Tomberlin SDX-200 T-14 ATV |
|
Year of manufacture
|
2011 |
|
Type
|
ATV |
|
Rating
|
Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
|
Engine and transmission |
|
Engine size
|
177.3 ccm (10.82 cubic inches) |
|
Type of engine
|
Single cylinder, four-stroke |
|
Torque
|
9.0 Nm (0.9 kgf-m or 6.6 ft.lbs) @ 5500 RPM |
|
Compression
|
8.8:1 |
|
Bore x stroke
|
82.5 x 57.8 mm (3.2 x 2.3 inches) |
|
Fuel system
|
Carburettor. ENI |
|
Fuel control
|
Overhead Valves (OHV) |
|
Ignition
|
CDI |
|
Lubrication system
|
Forced Pressure Wet Sump |
|
Cooling system
|
Air |
|
Transmission type
|
Belt (final drive) |
|
Chassis, suspension, brakes and wheels |
|
Front suspension
|
McPherson Strut |
|
Rear suspension
|
Swing Arm, coil over, adjustable shocks |
|
Front tire
|
22/7-12 |
|
Rear tire
|
22/10-10 |
|
Front brakes
|
Single disc. Hydraulic |
|
Rear brakes
|
Single disc. Hydraulic |
|
Physical measures and capacities |
|
Dry weight
|
236.3 kg (521.0 pounds) |
|
Overall height
|
1168 mm (46.0 inches) |
|
Overall length
|
2014 mm (79.3 inches) |
|
Overall width
|
1120 mm (44.1 inches) |
|
Wheelbase
|
1204 mm (47.4 inches) |
|
Other specifications |
|
Color options
|
Red, yellow |
|
Starter
|
Electric |
|
Light
|
Dual front lights |
