General information |
|
Model name
|
TGB Gunner 550 |
|
Year of manufacture
|
2012 |
|
Type
|
ATV |
|
Rating
|
Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
|
Engine and transmission |
|
Engine size
|
502.6 ccm (30.67 cubic inches) |
|
Type of engine
|
Single cylinder, four-stroke |
|
Output
|
18.9 HP (13.8 kW)) @ 5500 RPM |
|
Torque
|
31.6 Nm (3.2 kgf-m or 23.3 ft.lbs) @ 3600 RPM |
|
Compression
|
9.9:1 |
|
Bore x stroke
|
92.0 x 76.5 mm (3.6 x 3.0 inches) |
|
Fuel system
|
Injection. PFI |
|
Ignition
|
Electric CDI |
|
Gearbox
|
Automatic |
|
Transmission type
|
Shaft drive (cardan) (final drive) |
|
Driveline
|
4x4. Gear Selection L/H/N/R. CVT Automatic. |
|
Chassis, suspension, brakes and wheels |
|
Front suspension
|
Double AArm |
|
Rear suspension
|
Double AArm |
|
Front tire
|
25/8-12 |
|
Rear tire
|
25/10-12 |
|
Front brakes
|
Single disc |
|
Rear brakes
|
Single disc |
|
Physical measures and capacities |
|
Dry weight
|
330.0 kg (727.5 pounds) |
|
Power/weight ratio
|
0.0573 HP/kg |
|
Seat height
|
920 mm (36.2 inches) If adjustable, lowest setting. |
|
Overall height
|
1245 mm (49.0 inches) |
|
Overall length
|
2060 mm (81.1 inches) |
|
Overall width
|
1330 mm (52.4 inches) |
|
Ground clearance
|
305 mm (12.0 inches) |
|
Wheelbase
|
1320 mm (52.0 inches) |
|
Fuel capacity
|
15.00 litres (3.96 US gallons) |
|
Other specifications |
|
Color options
|
White, red |
|
Starter
|
Electric |
|
Comments
|
4W/2WD. Automatic Transmission with Hi/Lo Range and Reverse. |
